Dunkermotoren NG Series Gearbox - 16:1 Reduction Ratio, 21 N·m Torque

Name: Dunkermotoren NG Series Gearbox - 16:1 Reduction Ratio, 21 N·m Torque
Brand: Dunkermotoren
SKU: NGS-2e002e
Price: 499.99 USD
Availability: OutOfStock

SKU:NGS-2e002e

Enhance efficiency and durability with Dunkermotoren NG Series Gearbox - 16:1 Reduction Ratio, 21 N·m Torque.

$499.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Dunkermotoren NG Series Gearbox offers exceptional performance with an 85% efficiency and a 16:1 reduction ratio, providing a continuous torque of 21 N·m. Designed for durability and efficiency, this gearbox features lifetime lubrication, high torque capacity, vibration resistance, and a long-life version. With a maximum backlash of 40 arc-min, radial load capacity of 5000 N, and axial load capacity of 1667 N, this gearbox is ideal for industrial applications that demand reliability and robust performance.

Product Specifications

Features Features

Lifetime lubricationHigh efficiencyVibration resistanceHigh torqueLonglife version

Technical Specs Acceleration Torque

42 NÂ·m

Technical Specs Axial Load

1667 N

Technical Specs Brands

Dunkermotoren

Technical Specs Continuous Torque

21 NÂ·m

Technical Specs Efficiency

85 %

Technical Specs Emergency Stop Torque

63 NÂ·m

Technical Specs Maximum Backlash

40 arc-min

Technical Specs Number Of Stages

Technical Specs Operating Mode

S1 | S8

Technical Specs Product Availability

Preferred Series

Technical Specs Protection Class

Ingress Protection (IP54)

Technical Specs Radial Load

5000 N

Technical Specs Reduction Ratio

Technical Specs Series

Technical Specs Weight Of Gearbox

9.2 kg

Dunkermotoren NG Series Gearbox - 16:1 Reduction Ratio, 21 N·m Torque
