Dunkermotoren PLG 100 Series Planetary Gearbox
Dunkermotoren PLG 100 Series Planetary Gearbox
SKU:PLG-c1042d
Compact, high-torque Dunkermotoren PLG 100 Series Planetary Gearbox with 100:1 reduction ratio and 14 N·m continuous torque. Maintenance-free, lightweight design for industrial applications.
Regular price
$349.99
Regular price
Sale price
$349.99
Unit price
per
Initiate Order
Dunkermotoren PLG 100 Series Planetary Gearbox
$349.99
Quantity: 1
Claim Your Seller Account
Dunkermotoren PLG 100 Series Planetary Gearbox
$349.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dunkermotoren PLG 100 Series Planetary Gearbox is a compact and high-performance gearbox designed for industrial applications. With a reduction ratio of 100 and continuous torque up to 14 N·m, this gearbox offers exceptional efficiency at 73%. Featuring a maintenance-free design, lifetime lubrication, and vibration resistance, it ensures reliable performance. Built with steel ring gear material and dual ball bearings on the output shaft, this gearbox is lightweight (0.47 kg) yet robust enough to handle axial loads up to 150 N and radial loads up to 250 N. Ideal for applications requiring high torque and energy efficiency, the PLG 100 Series meets stringent industry standards and is suitable for various material combinations.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Additional Information Additional Information
Planetary gearboxes (PLG) have the highest continuous torque capacity of all types of gearbox; at the same time they have a very compact design, low weight and excellent gear efficiency of typically 97%. For our planetary gearboxes there are, depending on customer requirements, a variety of different materials combinable, whereby continuous torques reach up to 130 Nm, and ratios from 4:1 to 512:1 are available. The planetary gearboxes are maintenance-free.
Features Features
Lifetime lubricationFood grade lubricationLow temperatureHigh efficiencyHigh torqueSpecial surface availableVibration resistance
Technical Specs Axial Load
150 N
Technical Specs Brands
Dunkermotoren
Technical Specs Continuous Torque
0 to 14 N·m
Technical Specs Efficiency
73 %
Technical Specs Note For Axialradial Load
From center of shaft
Technical Specs Number Of Stages
3
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Up to Ingress Protection (IP50)
Technical Specs Radial Load
250 N
Technical Specs Reduction Ratio
100
Technical Specs Ring Gear Material
Steel
Technical Specs Series
PLG
Technical Specs Weight Of Gearbox
0.47 kg
