The Dunkermotoren PLG Series 14.06 Reduction Ratio Gearbox offers exceptional performance with a continuous torque of 0.70 N·m, high efficiency at 77%, and a compact planetary design. With a reduction ratio optimized for power and durability, this gearbox is ideal for demanding applications requiring reliability and longevity. Featuring lifetime lubrication, food-grade lubrication, and vibration resistance, this gearbox ensures smooth operation and minimal maintenance, making it a preferred choice for industrial and institutional needs.
Product Specifications
Additional Information Additional Information
Planetary gearboxes (PLG) have the highest continuous torque capacity of all types of gearbox; at the same time they have a very compact design, low weight and excellent gear efficiency of typically 97%. For our planetary gearboxes there are, depending on customer requirements, a variety of different materials combinable, whereby continuous torques reach up to 130 Nm, and ratios from 4:1 to 512:1 are available. The planetary gearboxes are maintenance-free.The construction sizes are partly available to different degrees:HT: High power density / extra robust / all duty cycles / IP 65. Gearbox body up to IP 65. Then the drive shaft has got IP 52 and gets heightened up to a better protection class by the customer if necessary.
Features Features
Lifetime lubricationFood grade lubricationLow temperature lubricationHigh efficiencyHigh torqueVibration resistance
Technical Specs Acceleration Torque
0.95 N·m
Technical Specs Axial Load 4 Millimeter Mm Shaft
16 N
Technical Specs Axial Load 6 Millimeter Mm Shaft
45 N
Technical Specs Brands
Dunkermotoren
Technical Specs Continuous Torque
0.70 N·m
Technical Specs Efficiency
77 %
Technical Specs Emergency Stop Torque
3.00 N·m
Technical Specs Maximum Backlash
114 arc-min
Technical Specs Note For Acceleration Torque
Only for 6 mm shaft
Technical Specs Note For Axialradial Load
10 mm off mounting surface
Technical Specs Note For Continuous Torque
Only for 6 mm shaft
Technical Specs Note For Emergency Stop Torque
Only for 6 mm shaft
Technical Specs Number Of Stages
2
Technical Specs Operating Mode
S1 | S8
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP52)
Technical Specs Radial Load 4 Millimeter Mm Shaft
48 N
Technical Specs Radial Load 6 Millimeter Mm Shaft
135 N
Technical Specs Reduction Ratio
14.06
Technical Specs Ring Gear Material
Steel
Technical Specs Series
PLG
Technical Specs Weight Of Gearbox
0.08 kg
