Dunkermotoren PLG 20.25 Reduction Ratio Gearbox
Dunkermotoren PLG 20.25 Reduction Ratio Gearbox
SKU:PLG-31bd7b
Enhance performance with Dunkermotoren PLG 20.25 Reduction Ratio Gearbox. Efficient, precise, and maintenance-free.
Regular price
$249.99
Regular price
Sale price
$249.99
Unit price
per
Initiate Order
Dunkermotoren PLG 20.25 Reduction Ratio Gearbox
$249.99
Quantity: 1
Claim Your Seller Account
Dunkermotoren PLG 20.25 Reduction Ratio Gearbox
$249.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dunkermotoren PLG 20.25 Reduction Ratio Gearbox from the PLG 22 to 60 Series is designed for optimal performance in various applications. With an efficiency of 81% and a continuous torque of 0.8 N·m, this gearbox offers high precision and reliability. It features low noise, lifetime lubrication, and vibration resistance, making it ideal for institutional and government procurement needs. The maintenance-free planetary design ensures a compact structure with excellent gear efficiency, meeting the highest continuous torque capacity standards.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Additional Information Additional Information
Planetary gearboxes (PLG) have the highest continuous torque capacity of all types of gearbox; at the same time they have a very compact design, low weight and excellent gear efficiency of typically 97%. For our planetary gearboxes there are, depending on customer requirements, a variety of different materials combinable, whereby continuous torques reach up to 130 Nm, and ratios from 4:1 to 512:1 are available. The planetary gearboxes are maintenance-free.
Features Features
Low noiseLifetime lubricationFood grade lubricationLow temperature lubricationVibration resistance
Note Note
Minimum quantity - 100 pcs
Technical Specs Axial Load
10 N
Technical Specs Brands
Dunkermotoren
Technical Specs Continuous Torque
0.8 N·m
Technical Specs Efficiency
81 %
Technical Specs Note For Axialradial Load
From center of shaft
Technical Specs Number Of Stages
2
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP50)
Technical Specs Radial Load
24 N
Technical Specs Reduction Ratio
20.25
Technical Specs Series
PLG
Technical Specs Weight Of Gearbox
0.08 kg
