Dunkermotoren PLG 225 Reduction Ratio Gearbox

Dunkermotoren PLG 225 Reduction Ratio Gearbox

PLG-155dba

Achieve superior efficiency and high torque with the Dunkermotoren PLG 225 Reduction Ratio Gearbox. Ideal for industrial applications.

$349.99
$349.99
Sale

Initiate Order

Dunkermotoren PLG 225 Reduction Ratio Gearbox

Dunkermotoren PLG 225 Reduction Ratio Gearbox

$349.99

Quantity: 1

Claim Your Seller Account

Dunkermotoren PLG 225 Reduction Ratio Gearbox

Dunkermotoren PLG 225 Reduction Ratio Gearbox

$349.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The Dunkermotoren PLG 225 Reduction Ratio Gearbox from the PLG 22 to 60 Series offers superior efficiency with a 73% efficiency rating. With a continuous torque of 10 Nm and 3 stages of straight toothing, this gearbox ensures smooth operation with low noise and vibration resistance. Ideal for institutional and industrial applications demanding high continuous torque capacity in a compact, maintenance-free design.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Additional Information Additional Information
Planetary gearboxes (PLG) have the highest continuous torque capacity of all types of gearbox; at the same time they have a very compact design, low weight and excellent gear efficiency of typically 97%. For our planetary gearboxes there are, depending on customer requirements, a variety of different materials combinable, whereby continuous torques reach up to 130 Nm, and ratios from 4:1 to 512:1 are available. The planetary gearboxes are maintenance-free.
Features Features
Low noiseLifetime lubricationFood grade lubricationLow temperatureSpecial surface availableVibration resistance
Technical Specs Acceleration Torque
18 N·m
Technical Specs Axial Load
500 N
Technical Specs Brands
Dunkermotoren
Technical Specs Continuous Torque
10 N·m
Technical Specs Efficiency
73 %
Technical Specs Emergency Stop Torque
48 N·m
Technical Specs Note For Acceleration Torque
Acceleration torque for maximum 1 second
Technical Specs Number Of Stages
3
Technical Specs Operating Mode
S1 | S8
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP50)
Technical Specs Radial Load
350 N
Technical Specs Reduction Ratio
225
Technical Specs Ring Gear Material
Steel
Technical Specs Series
PLG
Technical Specs Weight Of Gearbox
0.9 kg
