Dunkermotoren PLG Series 16 Reduction Gearbox
Dunkermotoren PLG Series 16 Reduction Gearbox
SKU:PLG-c07da0
Compact, high-torque Dunkermotoren gearbox with dual ball bearings, ideal for industrial applications.
Regular price
$249.99
Regular price
Sale price
$249.99
Unit price
per
Initiate Order
Dunkermotoren PLG Series 16 Reduction Gearbox
$249.99
Quantity: 1
Claim Your Seller Account
Dunkermotoren PLG Series 16 Reduction Gearbox
$249.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dunkermotoren PLG Series 16 Reduction Gearbox is an industry-leading solution for applications requiring a compact design, high torque output, and exceptional efficiency. With an 81% efficiency rating, dual ball bearing output shaft, and steel ring gear material, this gearbox offers up to 6 N·m continuous torque with an impressive weight of 0.37 kg. Designed for reliability and performance, this gearbox is maintenance-free, food-grade lubricated, and provides vibration resistance, making it ideal for various industrial settings.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Additional Information Additional Information
Planetary gearboxes (PLG) have the highest continuous torque capacity of all types of gearbox; at the same time they have a very compact design, low weight and excellent gear efficiency of typically 97%. For our planetary gearboxes there are, depending on customer requirements, a variety of different materials combinable, whereby continuous torques reach up to 130 Nm, and ratios from 4:1 to 512:1 are available. The planetary gearboxes are maintenance-free.
Features Features
Lifetime lubricationFood grade lubricationLow temperatureHigh efficiencyHigh torqueSpecial surface availableVibration resistance
Technical Specs Axial Load
150 N
Technical Specs Brands
Dunkermotoren
Technical Specs Continuous Torque
0 to 6 N·m
Technical Specs Efficiency
81 %
Technical Specs Note For Axialradial Load
From center of shaft
Technical Specs Number Of Stages
2
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Up to Ingress Protection (IP50)
Technical Specs Radial Load
250 N
Technical Specs Reduction Ratio
16
Technical Specs Ring Gear Material
Steel
Technical Specs Series
PLG
Technical Specs Weight Of Gearbox
0.37 kg
