Dunkermotoren PLG Series 200 Gearbox

Dunkermotoren PLG Series 200 Gearbox

SKU:PLG-5e68d3

Achieve peak performance with Dunkermotoren's PLG 200 Gearbox. High torque, compact design, ultimate reliability.

Regular price $149.99
Regular price Sale price $149.99
Sale

Initiate Order

Dunkermotoren PLG Series 200 Gearbox

Dunkermotoren PLG Series 200 Gearbox

$149.99

Quantity: 1

Claim Your Seller Account

Dunkermotoren PLG Series 200 Gearbox

Dunkermotoren PLG Series 200 Gearbox

$149.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The Dunkermotoren PLG Series 200 Gearbox is a premium solution designed for superior performance and reliability. With a high reduction ratio of 200 and a continuous torque of 3 N·m, this gearbox ensures efficient power transmission. Featuring a compact design, double ball bearings on the output shaft, and straight toothing on all stages, this gearbox offers exceptional quality and durability. Ideal for applications requiring high continuous torque capacity, vibration resistance, and lifetime lubrication, the PLG Series 200 Gearbox delivers excellent gear efficiency and low weight for optimal performance.

Product Specifications

Additional Information Additional Information
Planetary gearboxes (PLG) have the highest continuous torque capacity of all types of gearbox; at the same time they have a very compact design, low weight and excellent gear efficiency of typically 97%. For our planetary gearboxes there are, depending on customer requirements, a variety of different materials combinable, whereby continuous torques reach up to 130 Nm, and ratios from 4:1 to 512:1 are available. The planetary gearboxes are maintenance-free.
Features Features
Lifetime lubricationVibration resistance
Technical Specs Axial Load
150 N
Technical Specs Brands
Dunkermotoren
Technical Specs Continuous Torque
3 N·m
Technical Specs Efficiency
73 %
Technical Specs Note For Axialradial Load
From center of shaft
Technical Specs Number Of Stages
3
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP50)
Technical Specs Radial Load
230 N
Technical Specs Reduction Ratio
200
Technical Specs Ring Gear Material
Plastic
Technical Specs Series
PLG
Technical Specs Weight Of Gearbox
0.25 kg
