Dunkermotoren PLG Series 25 Planetary Gearbox
Dunkermotoren PLG Series 25 Planetary Gearbox
SKU:PLG-934717
Dunkermotoren PLG Series 25 Gearbox: High torque, efficiency & durability for diverse applications. Dual ball bearings & lifetime lubrication.
Regular price
$289.99
Regular price
Sale price
$289.99
Unit price
per
Initiate Order
Dunkermotoren PLG Series 25 Planetary Gearbox
$289.99
Quantity: 1
Claim Your Seller Account
Dunkermotoren PLG Series 25 Planetary Gearbox
$289.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dunkermotoren PLG Series 25 Planetary Gearbox offers unmatched continuous torque of up to 6 N·m, with an efficiency of 81%. It features dual ball bearings on the output shaft, straight toothing, and a compact design for industry compatibility. With lifetime lubrication, food-grade compatibility, and high efficiency, this gearbox ensures top performance in various applications. Meeting rigorous institutional standards, this gearbox is maintenance-free and combines high torque with a lightweight construction.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Additional Information Additional Information
Planetary gearboxes (PLG) have the highest continuous torque capacity of all types of gearbox; at the same time they have a very compact design, low weight and excellent gear efficiency of typically 97%. For our planetary gearboxes there are, depending on customer requirements, a variety of different materials combinable, whereby continuous torques reach up to 130 Nm, and ratios from 4:1 to 512:1 are available. The planetary gearboxes are maintenance-free.
Features Features
Lifetime lubricationFood grade lubricationLow temperatureHigh efficiencyHigh torqueSpecial surface availableVibration resistance
Technical Specs Axial Load
150 N
Technical Specs Brands
Dunkermotoren
Technical Specs Continuous Torque
0 to 6 N·m
Technical Specs Efficiency
81 %
Technical Specs Note For Axialradial Load
From center of shaft
Technical Specs Number Of Stages
2
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Up to Ingress Protection (IP50)
Technical Specs Radial Load
250 N
Technical Specs Reduction Ratio
25
Technical Specs Ring Gear Material
Steel
Technical Specs Series
PLG
Technical Specs Weight Of Gearbox
0.37 kg
