Dunkermotoren PLG Series 32 Gearbox
Dunkermotoren PLG Series 32 Gearbox
SKU:PLG-01a9ab
Compact and efficient, the Dunkermotoren PLG Series 32 Gearbox provides high torque and reliability for institutional applications.
Regular price
$159.99
Regular price
Sale price
$159.99
Unit price
per
Initiate Order
Dunkermotoren PLG Series 32 Gearbox
$159.99
Quantity: 1
Claim Your Seller Account
Dunkermotoren PLG Series 32 Gearbox
$159.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dunkermotoren PLG Series 32 Gearbox offers a high efficiency solution with a reduction ratio of 32 and continuous torque of 1.3 N·m. Featuring a compact design, double ball bearing output shaft, and straight toothing, this planetary gearbox ensures smooth operation and durability. Ideal for institutional applications requiring precision and reliability, the PLG Series gearbox boasts 97% gear efficiency and a lightweight build for easy integration.
Product Specifications
Additional Information Additional Information
Planetary gearboxes (PLG) have the highest continuous torque capacity of all types of gearbox; at the same time they have a very compact design, low weight and excellent gear efficiency of typically 97%. For our planetary gearboxes there are, depending on customer requirements, a variety of different materials combinable, whereby continuous torques reach up to 130 Nm, and ratios from 4:1 to 512:1 are available. The planetary gearboxes are maintenance-free.
Features Features
Lifetime lubricationVibration resistance
Technical Specs Axial Load
150 N
Technical Specs Brands
Dunkermotoren
Technical Specs Continuous Torque
1.3 N·m
Technical Specs Efficiency
81 %
Technical Specs Note For Axialradial Load
From center of shaft
Technical Specs Number Of Stages
2
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP50)
Technical Specs Radial Load
230 N
Technical Specs Reduction Ratio
32
Technical Specs Ring Gear Material
Plastic
Technical Specs Series
PLG
Technical Specs Weight Of Gearbox
0.2 kg
