Dunkermotoren PLG Series 4 Gearbox
Dunkermotoren PLG Series 4 Gearbox
SKU:PLG-715cae
Compact and powerful, the Dunkermotoren PLG Series 4 Gearbox delivers high torque with exceptional efficiency for industrial applications.
Regular price
$199.99
Regular price
Sale price
$199.99
Unit price
per
Initiate Order
Dunkermotoren PLG Series 4 Gearbox
$199.99
Quantity: 1
Claim Your Seller Account
Dunkermotoren PLG Series 4 Gearbox
$199.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dunkermotoren PLG Series 4 Gearbox offers unmatched performance in a compact design. With a reduction ratio of 4:1 and a continuous torque of 3.5 Nm, this planetary gearbox ensures high efficiency (90%) and durability. It features a steel ring gear, lifetime lubrication, and low weight, making it ideal for a wide range of industrial applications. This gearbox meets stringent industry standards, providing reliability and precision for your machinery.
Product Specifications
Additional Information Additional Information
Planetary gearboxes (PLG) have the highest continuous torque capacity of all types of gearbox; at the same time they have a very compact design, low weight and excellent gear efficiency of typically 97%. For our planetary gearboxes there are, depending on customer requirements, a variety of different materials combinable, whereby continuous torques reach up to 130 Nm, and ratios from 4:1 to 512:1 are available. The planetary gearboxes are maintenance-free.
Features Features
Lifetime lubricationFood grade lubricationLow temperatureHigh efficiencyHigh torqueSpecial surface availableVibration resistance
Technical Specs Axial Load
150 N
Technical Specs Brands
Dunkermotoren
Technical Specs Continuous Torque
3.5 N·m
Technical Specs Continuous Torque No Metallic Planet Gears
0 to 0.7 N·m
Technical Specs Efficiency
90 %
Technical Specs Note For Axialradial Load
From center of shaft
Technical Specs Number Of Stages
1
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Up to Ingress Protection (IP50)
Technical Specs Radial Load
250 N
Technical Specs Reduction Ratio
4
Technical Specs Ring Gear Material
Steel
Technical Specs Series
PLG
Technical Specs Weight Of Gearbox
0.27 kg
