The Dunkermotoren PLG Series 8 Gearbox offers high efficiency and a compact design suitable for various applications. With a reduction ratio of 8 and continuous torque of 0.7 Nm, this gearbox ensures reliable performance. It features lifetime lubrication, vibration resistance, and a maintenance-free operation. The gearbox is ideal for applications requiring a balance of power and efficiency while maintaining a lightweight and durable construction. Compliant with industry standards, this gearbox meets the rigorous requirements of institutional and government procurement.
Product Specifications
Additional Information Additional Information
Planetary gearboxes (PLG) have the highest continuous torque capacity of all types of gearbox; at the same time they have a very compact design, low weight and excellent gear efficiency of typically 97%. For our planetary gearboxes there are, depending on customer requirements, a variety of different materials combinable, whereby continuous torques reach up to 130 Nm, and ratios from 4:1 to 512:1 are available. The planetary gearboxes are maintenance-free.
Features Features
Lifetime lubricationVibration resistance
Technical Specs Axial Load
150 N
Technical Specs Brands
Dunkermotoren
Technical Specs Continuous Torque
0.70 N·m
Technical Specs Efficiency
90 %
Technical Specs Note For Axialradial Load
From center of shaft
Technical Specs Number Of Stages
1
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP50)
Technical Specs Radial Load
230 N
Technical Specs Reduction Ratio
8
Technical Specs Ring Gear Material
Plastic
Technical Specs Series
PLG
Technical Specs Weight Of Gearbox
0.16 kg
