The Dunkermotoren PLG Series Gearbox offers a superior reduction ratio of 156.25, delivering up to 14 N·m of continuous torque. With a compact planetary design, dual ball bearing output shaft, and straight toothing in all stages, this gearbox ensures industry compatibility and optimal performance. Featuring a 73% efficiency, lightweight construction, and high torque capability, this gearbox is ideal for applications requiring reliable, high-performance gear solutions. With lifetime lubrication, food-grade options, and maintenance-free operation, the Dunkermotoren PLG Series Gearbox guarantees long-lasting durability and efficiency.
Product Specifications
Additional Information Additional Information
Planetary gearboxes (PLG) have the highest continuous torque capacity of all types of gearbox; at the same time they have a very compact design, low weight and excellent gear efficiency of typically 97%. For our planetary gearboxes there are, depending on customer requirements, a variety of different materials combinable, whereby continuous torques reach up to 130 Nm, and ratios from 4:1 to 512:1 are available. The planetary gearboxes are maintenance-free.
Features Features
Lifetime lubricationFood grade lubricationLow temperatureHigh efficiencyHigh torqueSpecial surface availableVibration resistance
Technical Specs Axial Load
150 N
Technical Specs Brands
Dunkermotoren
Technical Specs Continuous Torque
0 to 14 N·m
Technical Specs Efficiency
73 %
Technical Specs Note For Axialradial Load
From center of shaft
Technical Specs Number Of Stages
3
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Up to Ingress Protection (IP50)
Technical Specs Radial Load
250 N
Technical Specs Reduction Ratio
156.25
Technical Specs Ring Gear Material
Steel
Technical Specs Series
PLG
Technical Specs Weight Of Gearbox
0.47 kg
