Dunkermotoren PLG Series Gearbox with 156.25 Reduction Ratio and 3 N·m Torque
Dunkermotoren PLG Series Gearbox with 156.25 Reduction Ratio and 3 N·m Torque
SKU:PLG-bad69b
High-efficiency Dunkermotoren PLG Gearbox with 156.25 Ratio & 3 N·m Torque
Regular price
$349.99
Regular price
Sale price
$349.99
Unit price
per
Initiate Order
Dunkermotoren PLG Series Gearbox with 156.25 Reduction Ratio and 3 N·m Torque
$349.99
Quantity: 1
Claim Your Seller Account
Dunkermotoren PLG Series Gearbox with 156.25 Reduction Ratio and 3 N·m Torque
$349.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dunkermotoren PLG Series Gearbox offers exceptional performance with a 156.25 reduction ratio and a continuous torque of 3 N·m. With high efficiency and double ball bearings on the output shaft, this gearbox ensures reliable operation. Featuring a compact design and lifetime lubrication, these planetary gearboxes combine superior torque capacity, lightweight construction, and excellent gear efficiency. Ideal for various applications, this gearbox is maintenance-free and showcases vibration resistance.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Additional Information Additional Information
Planetary gearboxes (PLG) have the highest continuous torque capacity of all types of gearbox; at the same time they have a very compact design, low weight and excellent gear efficiency of typically 97%. For our planetary gearboxes there are, depending on customer requirements, a variety of different materials combinable, whereby continuous torques reach up to 130 Nm, and ratios from 4:1 to 512:1 are available. The planetary gearboxes are maintenance-free.
Features Features
Lifetime lubricationVibration resistance
Technical Specs Axial Load
150 N
Technical Specs Brands
Dunkermotoren
Technical Specs Continuous Torque
3 N·m
Technical Specs Efficiency
73 %
Technical Specs Note For Axialradial Load
From center of shaft
Technical Specs Number Of Stages
3
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP50)
Technical Specs Radial Load
230 N
Technical Specs Reduction Ratio
156.25
Technical Specs Ring Gear Material
Plastic
Technical Specs Series
PLG
Technical Specs Weight Of Gearbox
0.25 kg
