Dunkermotoren PLG Series Planetary Gearbox 50 Ratio & Up to 6 Nm Torque

Dunkermotoren PLG Series Planetary Gearbox 50 Ratio & Up to 6 Nm Torque

SKU:PLG-0a4cae

Compact, high-torque Dunkermotoren PLG Series 50 Ratio Planetary Gearbox with lifetime lubrication and high efficiency.

Regular price $199.99
Regular price Sale price $199.99
Sale

Initiate Order

Dunkermotoren PLG Series Planetary Gearbox 50 Ratio & Up to 6 Nm Torque

Dunkermotoren PLG Series Planetary Gearbox 50 Ratio & Up to 6 Nm Torque

$199.99

Quantity: 1

Claim Your Seller Account

Dunkermotoren PLG Series Planetary Gearbox 50 Ratio & Up to 6 Nm Torque

Dunkermotoren PLG Series Planetary Gearbox 50 Ratio & Up to 6 Nm Torque

$199.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The Dunkermotoren PLG Series 50 Ratio Planetary Gearbox offers a compact design, dual ball bearings on the output shaft, straight toothing in all stages, and an efficiency of 81%. With a continuous torque range of 0 to 6 Nm, this gearbox is lightweight at 0.37 kg, suitable for applications requiring up to 150 N axial load and 250 N radial load. Featuring high efficiency, high torque, low temperature operation, and lifetime lubrication, these gearboxes are designed for durability, vibration resistance, and maintenance-free use. Customize materials for various torque and ratio requirements up to 130 Nm and ratios from 4:1 to 512:1 for optimal performance.

Product Specifications

Additional Information Additional Information
Planetary gearboxes (PLG) have the highest continuous torque capacity of all types of gearbox; at the same time they have a very compact design, low weight and excellent gear efficiency of typically 97%. For our planetary gearboxes there are, depending on customer requirements, a variety of different materials combinable, whereby continuous torques reach up to 130 Nm, and ratios from 4:1 to 512:1 are available. The planetary gearboxes are maintenance-free.
Features Features
Lifetime lubricationFood grade lubricationLow temperatureHigh efficiencyHigh torqueSpecial surface availableVibration resistance
Technical Specs Axial Load
150 N
Technical Specs Brands
Dunkermotoren
Technical Specs Continuous Torque
0 to 6 N·m
Technical Specs Efficiency
81 %
Technical Specs Note For Axialradial Load
From center of shaft
Technical Specs Number Of Stages
2
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Up to Ingress Protection (IP50)
Technical Specs Radial Load
250 N
Technical Specs Reduction Ratio
50
Technical Specs Ring Gear Material
Steel
Technical Specs Series
PLG
Technical Specs Weight Of Gearbox
0.37 kg
