Dunkermotoren SL 38 M Series Linear Motor
Dunkermotoren SL 38 M Series Linear Motor
SKU:LIN-54b816
Experience high precision and dynamic force with Dunkermotoren SL 38 M Series Linear Motor.
Regular price
$1,699.99
Regular price
Sale price
$1,699.99
Unit price
per
Initiate Order
Dunkermotoren SL 38 M Series Linear Motor
$1,699.99
Quantity: 1
Claim Your Seller Account
Dunkermotoren SL 38 M Series Linear Motor
$1,699.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dunkermotoren SL 38 M Series 1581N Peak Force Linear Motor is a highly dynamic 3-phase linear motor featuring a peak current of 30A at 25°C, ensuring precise positioning and high force output. With a nominal DC voltage of 325V and integrated linear encoder, this motor offers maintenance-free operation, low noise, and resistance to vibrations. Meeting IP65 protection standards and European Conformity (CE), Dunkermotoren assures a quality linear motor suitable for a wide range of applications.
Product Specifications
Additional Information Additional Information
Standard version with connection for water coolingCan be operated with commercially servo controllers, settings available (Schneider, Siemens, etc.)
Features Features
Force modePrecise positioningMaintenance freeLow noiseHigh ForceHigh dynamicFood gradeSpecial surface availableVibration resistance
Technical Specs Brands
Dunkermotoren
Technical Specs Continous Power
615 W
Technical Specs Feedback Integrated
1 Vss | Bidirectional Serial Synchronous (BISS) | Synchronous Serial Interface (SSI) | Transistor-Transistor Logic (TTL)
Technical Specs Forcer Mass
3.0 kg
Technical Specs Force Constant At 25 Degree Celsius C Temperatur
52.7 pk
Technical Specs Industry Standardscertifications
European Conformity (CE) | Underwriters Laboratories (UL)
Technical Specs Maximum Speed At 100 Degree Celsius C Temperatur
3.8 m/s
Technical Specs Nominal Current At 100 Degree Celsius C Temperat
2.4 A
Technical Specs Nominal Direct Current Dc Voltage
325 V
Technical Specs Nominal Force At 100 Degree Celsius C Temperatur
126 N
Technical Specs Note For Maximum Speed At 100 Degree Celsius C T
Moving magnetic rod with 4xx mm stroke
Technical Specs Note For Peak Acceleration At 100 Degree Celsius
Moving magnetic rod with 2x mm stroke
Technical Specs Peak Acceleration At 100 Degree Celsius C Temper
>200 m/s²
Technical Specs Peak Current At 25 Degree Celsius C Temperature
30 A
Technical Specs Peak Force At 25 Degree Celsius C Temperature
1581 N
Technical Specs Peak Power
3690 W
Technical Specs Pole Pitch
51.2 mm
Technical Specs Product Availability
On Request
Technical Specs Protection Class
Ingress Protection (IP65)
Technical Specs Rod Mass
8.3 kg/m
