Dunkermotoren SL38M Series 2637N Linear Motor
Dunkermotoren SL38M Series 2637N Linear Motor
SKU:LIN-1508ae
High-performance linear motor with 2637N peak force, precise positioning, and maintenance-free operation. Compliance with CE and UL standards for reliability.
Regular price
$1,499.99
Regular price
Sale price
$1,499.99
Unit price
per
Initiate Order
Dunkermotoren SL38M Series 2637N Linear Motor
$1,499.99
Quantity: 1
Claim Your Seller Account
Dunkermotoren SL38M Series 2637N Linear Motor
$1,499.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dunkermotoren SL38M Series 2637N Linear Motor is a high-performance 3-phase motor designed for precise positioning and maintenance-free operation. With a peak force of 2637N at 30A peak current, it offers high dynamic capabilities and low noise levels. This linear motor is integrated with a linear encoder and can be optionally equipped with limit switches and an absolute encoder. Its features include high force, vibration resistance, and compliance with industry standards like European Conformity (CE) and Underwriters Laboratories (UL). Suitable for various applications, this linear motor ensures efficient and reliable performance.
Product Specifications
Additional Information Additional Information
Standard version with connection for water coolingCan be operated with commercially servo controllers, settings available (Schneider, Siemens, etc.)
Features Features
Force modePrecise positioningMaintenance freeLow noiseHigh ForceHigh dynamicFood gradeSpecial surface availableVibration resistance
Technical Specs Brands
Dunkermotoren
Technical Specs Continous Power
615 W
Technical Specs Feedback Integrated
1 Vss | Bidirectional Serial Synchronous (BISS) | Synchronous Serial Interface (SSI) | Transistor-Transistor Logic (TTL)
Technical Specs Forcer Mass
5.0 kg
Technical Specs Force Constant At 25 Degree Celsius C Temperatur
87.9 pk
Technical Specs Industry Standardscertifications
European Conformity (CE) | Underwriters Laboratories (UL)
Technical Specs Maximum Speed At 100 Degree Celsius C Temperatur
4.4 m/s
Technical Specs Nominal Current At 100 Degree Celsius C Temperat
2.4 A
Technical Specs Nominal Direct Current Dc Voltage
560 V
Technical Specs Nominal Force At 100 Degree Celsius C Temperatur
211 N
Technical Specs Note For Maximum Speed At 100 Degree Celsius C T
Moving magnetic rod with 4xx mm stroke
Technical Specs Note For Peak Acceleration At 100 Degree Celsius
Moving magnetic rod with 2x mm stroke
Technical Specs Peak Acceleration At 100 Degree Celsius C Temper
>200 m/s²
Technical Specs Peak Current At 25 Degree Celsius C Temperature
30 A
Technical Specs Peak Force At 25 Degree Celsius C Temperature
2637 N
Technical Specs Peak Power
3690 W
Technical Specs Pole Pitch
51.2 mm
Technical Specs Product Availability
On Request
Technical Specs Protection Class
Ingress Protection (IP65)
Technical Specs Rod Mass
8.3 kg/m
