Duolok 45 Degree Positionable Male Elbow - Brass, 1/4" Tube x 7/16-20 SAE
Duolok 45 Degree Positionable Male Elbow - Brass, 1/4" Tube x 7/16-20 SAE
SKU:FIT-124753
Durable brass 45° male elbow for 1/4" tube x 7/16-20 SAE fittings. Versatile and reliable choice for fluid systems.
Regular price
$14.99
Regular price
Sale price
$14.99
Unit price
per
Initiate Order
Duolok 45 Degree Positionable Male Elbow - Brass, 1/4" Tube x 7/16-20 SAE
$14.99
Quantity: 1
Claim Your Seller Account
Duolok 45 Degree Positionable Male Elbow - Brass, 1/4" Tube x 7/16-20 SAE
$14.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Duolok 45° Positionable Male Elbow is expertly crafted from brass, ensuring durability and reliability in fluid systems. This elbow features a 1/4" tube fitting on one end and a 7/16-20 male SAE fitting on the other, providing secure and leak-free connections. With precise dimensions and a 45° angle for optimal positioning flexibility, this fitting is perfect for instrumentation tube applications. Compliant with industry standards, this Duolok male elbow offers premium quality for both consumer and institutional needs.
Product Specifications
Dimensions A
1.01 in
Dimensions As568 O Ring Uniform Size Number
-904
Dimensions Bx
0.72 in
Dimensions By
1.01 in
Dimensions C
0.70 in
Dimensions D
0.60 in
Dimensions E
0.19 in
Dimensions G
9/16 in
Dimensions H
1/2 in
Dimensions Hx
9/16 in
Dimensions S
7/16-20
Dimensions T
1/4 in
Specifications Body Material
Brass
Specifications Brand Series
Duolok
Specifications Connection 1 Size
1/4 in
Specifications Connection 1 Type
Tube Fitting
Specifications Connection 2 Size
1/4 in
Specifications Connection 2 Type
Male SAE
Specifications End Connections
TF x Male SAE
Specifications Handle Color
0
Specifications Handle Type
0
Specifications Production Category
4
Specifications Shape
Elbow
Category 6
Tube Fitting to SAE Thread Fitting - Duolok
