Duolok Calibration Union - Precision Calibration for Instrumentation Needs

$45.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Duolok Calibration Union in Alloy C-276 offers precise calibration with a 1/4-inch tube fitting on one end and a 5/16-24 UNF threaded calibration port on the other. Designed for durability and accuracy, this straight-shaped union ensures seamless integration in instrumentation applications. The Duolok brand's reputation for quality and reliability makes this fitting ideal for critical calibration requirements in diverse industrial settings.

Product Specifications

Specifications Case Material

Cold Rolled Steel (CRS)

Specifications Current

10 A

Specifications Dielectric Withstanding Voltage

100 VDC line-to-line & line-to-chassis per MIL-STD-202, Method 301

Specifications Insertion Loss

Per MIL-STD-220, see graphs

Specifications Insertion Loss Curve

Typical Insertion Loss Curve - 2

Specifications Insulation Resistance

10 MÎ© minimum line-to-line & line-to-chassis per MIL-STD-202, Method 302

Specifications Operating Temperature

-55 to +95 ÂºC

Specifications Size

Size - 2

Specifications Soldering

In accordance with J-STD-001 Class 3

Specifications Storage Temperature

-55 to +105 ÂºC

Specifications Terminal Strength

Per MIL-PRF-15733

Specifications Visualmechanical

Per MIL-PRF-15733, Paragraph 4.6.1

Specifications Voltage Rating Dc

28 V

Specifications Weight

~150 g
