Duolok Male Adapter - 1/4 Tube Stub x 1/8-27 MNPT, 316 SS
Duolok Male Adapter - 1/4 Tube Stub x 1/8-27 MNPT, 316 SS
SKU:MUL-85a23b
High-quality Duolok Male Adapter for instrumentation tube fittings, 316 SS construction, Tube Stub x MNPT connections.
Regular price
$7.86
Regular price
Sale price
$7.86
Unit price
per
Initiate Order
Duolok Male Adapter - 1/4 Tube Stub x 1/8-27 MNPT, 316 SS
$7.86
Quantity: 1
Claim Your Seller Account
Duolok Male Adapter - 1/4 Tube Stub x 1/8-27 MNPT, 316 SS
$7.86
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Duolok Male Adapter is a premium 316 SS fitting designed for precision and durability in instrumentation tube applications. Featuring a straight shape with Tube Stub x MNPT connections, this fitting ensures leak-free performance and efficient fluid transfer. With precise dimensions and high-quality materials, it meets the stringent standards of institutional procurement, making it an ideal choice for government facilities and industrial applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Features Features
Inner seal diameterOuter seal diameterHead pressure to hold backAny unusual chemical or temperature requirements
Inflatable Plug Warning Inflatable Plug Warning
Maximum head pressures that a pipe plug may restrain can only be estimated. Slippage is influenced by many factors including fluid in the pipe, coefficient of pipeline friction, pressure required to inflate the plug, and accuracy of pressure gauges. Generally, a Multi-Flex⢠Inflatable Plug inserted fully into pipeline will begin slipping between 50% and 80% of the inflation pressure if it has an inflated pipe contact length of 1 1/2 to 2 times the diameter, but even a head pressure of 50% of the inflation pressure may cause slippage with some liquids. The inflation pressure is also subject to temperature change and debris or protrusions in the pipeline that could rupture the plug. The inflation pressure should be monitored and plugs anchored and/or mechanically blocked when slippage could cause property damage or injury. NEVER use a test pressure greater than the capacity of the weakest pipe or component in the system. NEVER use an inflatable plug when its failure could cause injury or catastrophic damage. NEVER use an inflatable plug as the only means of protection for personnel working downstream.
Note Note
Other sizes available on request
Specifications Contact Length
8 in | 204 mm
Specifications Country Of Origin
USA
Specifications Inflation Port Location
Centered on Annular End
Specifications Inflation Port Size
1/4 in
Specifications Inflation Port Type
National Pipe Thread (NPT)
Specifications Inside Diameter
12.75 in | 324 mm
Specifications Location Of Positioning Loops
Each End Internal Diameter (ID)
Specifications Maximum Inflation
25 psi | 1.72 bar
Specifications Number Of Positioning Loops
4
Specifications Outer Diameter Od
17.25 in | 439 mm
Specifications Outer Ply Material
Ballistic Nylon Reinforced Polyurethane
Specifications Pressure Monitoring Port Location
Centered on Annular Seal
Specifications Pressure Monitoring Port Size
1/4 in
Specifications Pressure Monitoring Port Type
Quick Disconnect
