The DURA-COAT Conductor Bar Cut Lengths with Splice Installed is a robust solution designed for highly corrosive environments. With a 700A amperage rating and PVC material construction, this conductor bar excels in challenging conditions. It offers a maximum temperature of 160°F, UV-stable black cover, and a sturdy build suitable for both outdoor and indoor applications. Additionally, it boasts a high dielectric strength and flame resistance, ensuring safety and reliability in demanding environments. With support spacing of 7.5ft and various available accessories, this conductor bar delivers exceptional performance and versatility, making it an ideal choice for crane control systems.
Product Specifications
Cover Specifications Dielectric Strength
450 V/mil
Cover Specifications Flame Test
Self Extinguishing
Cover Specifications Normal Ambient
-40 to 104 ºF
Cover Specifications Specific Density
1.5 g/cm³
Cover Specifications Volume Resistivity
>1012 Ω/mil
Specifications Amperage Rating
700 A
Specifications Available Accessories
Pick-up Guides for discontinuous systems | Transfer Caps for switches | Vertical and horizontal curves
Specifications Cover Type
Phase & Ground / Outdoors UV Stable (Black)
Specifications Cross Sectional Area
0.70 in²
Specifications Length
5 to 29 ft
Specifications Material
PVC
Specifications Maximum System Voltage Ac Or Dc Per Ul Listing
4160 V | 600 V
Specifications Maximum Temperature
160 ºF
Specifications Minimum Bending Radius
10 ft
Specifications Phase Corrected Impedance Z At 20 C
4.21 x 10-5 c/ft
Specifications Resistance R For Dc At 20 C
2.11 x 10-5 c/ft
Specifications Spacing Between Conductors
3.0 in
Specifications Support Spacing
7.5 ft
Specifications Weight
1.31 lb/ft
