Durable Ball Type Check Valves - NPT Brass & SS Materials
Durable Ball Type Check Valves - NPT Brass & SS Materials
SKU:CHE-2ce46a
Reliable Ball Type Check Valves for precise flow control in liquids or gases. Durable construction with minimal leakage, ideal for industrial use.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Durable Ball Type Check Valves - NPT Brass & SS Materials
$29.99
Quantity: 1
Claim Your Seller Account
Durable Ball Type Check Valves - NPT Brass & SS Materials
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Ensure reliable fluid or gas flow control with our Ball Type Check Valves featuring all-metal construction, 304 SS ball, and high-pressure capability. With a cracking pressure of 15 psig, these valves prevent reverse flow efficiently. Suitable for liquids or gases, they offer long-term operation and minimal seat leakage. Ideal for industrial applications requiring precision and durability.
Product Specifications
Dimensions Total Length
1.25 in
Dimensions Width Across Flats Hex
3/4 in
Features Features
All metal construction Long life operation Choice of cracking pressure High pressure capability
Flow Data Air Flow At 100 Psig
781 ft³/h
Flow Data Water Flow At 100 Psig
1.9 gpm
Specifications Ball Material
304 SS
Specifications Connection A
1/4" NPT Female
Specifications Connection B
1/4" NPT Male
Specifications Cracking Pressure
15 psig
Specifications Cv
0.190
Specifications Material
Brass
Specifications Maximum Operating Pressure Gauge
200 psig
Specifications Maximum Temperature
300 ºF
Specifications Seat Leakage
20 SSCM (max.) air flow at 25 psi differential
