DVP-08 Flow Control Valve with Fluoroelastomer Seals

Name: DVP-08 Flow Control Valve with Fluoroelastomer Seals
Brand: HYDAC Technology Corporation
SKU: ACC-d0edad
Price: 189.99 USD
Availability: OutOfStock

SKU:ACC-d0edad

High-performance DVP-08 Flow Control Valve with precision flow regulation, color-coded spindle, and safety design.

$189.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The DVP-08 Flow Control Valve is a high-performance solution designed for precision flow regulation in industrial applications. Featuring SAE O-Ring and NPT or BSPP Threaded Connections, this valve ensures secure sealing and efficient flow control. Its color-coded spindle allows for easy and accurate adjustment, while the unique safety spindle design enhances operational safety. With a flow capacity of 80 gpm and an operating pressure of 5000 psi, this valve delivers reliable performance even in demanding conditions. Made of robust Carbon Steel with Fluoroelastomer seals, it guarantees durability and resilience. The provision for panel mounting adds to its versatility and ease of installation.

Product Specifications

Dimensions Diameter G

1.14 in | 29 mm

Dimensions Diameter H

0.75 in | 19 mm

Dimensions Dimension A

2.83 in | 72 mm

Dimensions Dimension B

2.56 in | 65 mm

Dimensions Dimension C

0.49 in | 12.5 mm

Dimensions Dimension D

0.98 in | 25 mm

Dimensions Dimension E

0.94 in | 24 mm

Dimensions Dimension F

1.89 in | 48 mm

Dimensions Dimension J

Pg 11 Thread

Specifications Bun

Specifications Division

ACCESSORIES

Specifications Finish

Zinc Plated

Specifications Flow

80 gpm

Specifications Housing Material

Carbon Steel

Specifications Material

Carbon Steel

Specifications Model Code Description

DVP-08-01.X/M

Specifications Operating Pressure

5000 psi

Specifications O Ring Material

Fluoroelastomer (FPM)

Specifications Product

FLOW CONTROL VALVES

Specifications Product Group Family

FLOW CONTROL VALVES

Specifications Seal Material

Fluoroelastomer (FKM)

Specifications Temperature Range At Full Pressure Max

-4 to 212 ÂºF

Specifications Valve Operator

Knob

Specifications Weight

0.25 kg | 0.55 lb

DVP-08 Flow Control Valve with Fluoroelastomer Seals
