Dymax D70 Medical Wearable Adhesive
Dymax D70 Medical Wearable Adhesive
SKU:MED-352b53
Revolutionize medical wearable assembly with the Dymax D70 Adhesive. Skin-friendly, biocompatible formula for safe and reliable bonding.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Dymax D70 Medical Wearable Adhesive
$39.99
Quantity: 1
Claim Your Seller Account
Dymax D70 Medical Wearable Adhesive
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dymax D70 Cured Durometer Hardness Medical Wearable Adhesive is a groundbreaking formula designed for medical wearable device assembly, free of skin irritants like IBOA and TPO. This adhesive cures quickly with UV/LED light, meeting ISO 10993-10/-23 for sensitization and irritation, and ISO 10993-5 for cytotoxicity. With a cured durometer hardness of D77, it offers exceptional bonding to various substrates crucial for medical wearables. Experience skin-friendly, biocompatible adhesion that ensure safety and reliability in medical device assembly.
Product Specifications
Additional Information Additional Information
LED-Curable Medical Wearable Adhesive For Skin Sensitivity ConcernsThe 2101-MW-UR is blazing the trail for the next generation in advanced medical-grade adhesives for wearables. As part of the 2000-MW product line, these adhesives are specifically designed to address skin sensitivity concerns through the removal of IBOA (isobornyl acrylate). 2101-MW-UR adhesive passes ISO 10993-10 skin irritation and sensitization and ISO 10993-5 cytotoxicity testing, making it an ideal option for smart medical wearable devices.2101-MW-UR is a light-cure adhesive that bonds using LED or ultra-violet light with a medium viscosity. The material also uses Ultra-Red® fluorescing for simple in-line inspection of UV curing materials. The medical adhesive forms a highly reliable bond to many plastics such as ABS, PC, PCTG, PETG, PVC, and TPU. This makes it an ideal substance to use for the assembly of medical smart devices, patient monitoring devices, large-volume injectors, or diabetes care devices.
Features Features
ISO 10993-10 (passes testing for skin irritation & sensitization)ISO 10993-5 (passes testing for cytotoxicity)IBOA Free (designed without isobornyl acrylate)TPO Free (designed without Diphenyl Trimethylbenzoyl Phosphine Oxide)Biocompatible 10993 standardsUltra-Red® Fluorescing for inspection
Specifications Boiling Water Absorption 24 Hours
4.5 %
Specifications Cured Durometer Hardness
D77
Specifications Cured Elongation At Break
80 %
Specifications Fluoresces
Yes
Specifications Industry Standards
International Organization for Standardization (ISO 10993-10) | International Organization for Standardization (ISO 10993-23) | International Organization for Standardization (ISO 10993-5)
Specifications Modulus Of Elasticity
1,020.4 MPa | 148,000 psi
Specifications Nominal Viscosity At 20 Revolutions Per Minute Rp
5,500 cP
Specifications Recommended Substrates
Acrylonitrile Butadiene Styrene (ABS) | Polycarbonate (PC) | Polycyclohexylene Dimethylene Terephthalate Glycol (PCTG) | Polyethylene Terephthalate Glycol (PETG) | Polyvinyl chloride (PVC) | Thermoplastic Polyurethane (TPU)
Specifications Tensile At Break
24.8 MPa | 3,600 psi
Specifications Uncured Appearance
Colorless to light yellow transparent liquid
Specifications Water Absorption 25 Degree Celsius C Temperature
2.1 %
