Dymax MD® 1100 cP Medical Device Adhesive
Dymax MD® 1100 cP Medical Device Adhesive
SKU:MDM-9839de
Dymax MD® 1100 cP Medical Device Adhesive: Rapidly bond medical-grade plastics under UV/Visible light. ISO 10993 compliant with strong substrate compatibility and fluorescence for quality inspection.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Dymax MD® 1100 cP Medical Device Adhesive
$39.99
Quantity: 1
Claim Your Seller Account
Dymax MD® 1100 cP Medical Device Adhesive
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dymax MD® 1100 cP Medical Device Adhesive is a versatile solution designed for rapid bonding of medical-grade plastics under UV/Visible light. This ISO 10993 compliant adhesive offers a nominal viscosity of 1,100 cP, ensuring strong and durable bonds with substrates like ABS, PC, PMMA, PVC, and more. With features like patented Encompass® technology for easy visual confirmation and fluorescence for quality inspection, this adhesive is ideal for in vitro diagnostics, transducer assembly, and medical potting applications. Its moisture resistance, Ultra-Red® fluorescing properties, and compatibility with various sterilization methods make it a reliable choice for medical device assembly.
Product Specifications
Additional Information Additional Information
Flexible Plastics Adhesive with Ultra-Red® Fluorescing TechnologyDymax® MD® 1172-M-UR medical device adhesive is designed for rapid bonding of COC, COP, and a variety of other plastics typically used in the manufacture of medical devices. Applications include in vitro diagnostics, reservoir assembly, transducer assembly, and medical potting. 1172-M-UR fluoresces bright red under low-intensity black light (365 nm). The bright red fluorescence contrasts extremely well on plastics that naturally fluoresce blue in color (like PVC), and greatly assists with visual inspection of bond-line area. This flexible, Ultra-Red® fluorescing product bonds a wide variety of substrates including COC, COP, ABS, PC, PMMA, PVC, EVA, PA, PCTG, PEBA, PEI, PET, PETG, PS, PSU, SAN, TPU, CER, AL, and Stainless Steel.Dymax® MD® medical device adhesives have no solvents added and cure upon exposure to light. Their ability to cure in seconds enables faster processing, greater output, and lower processing costs. When cured with Dymax® light-curing spot lamps, focused beam lamps, flood lamps, or conveyor systems they deliver optimum speed and performance for medical device assembly. Dymax® lamps offer the optimum balance of UV and visible light for the fastest, deepest cures.MD® 1172-M-UR medical device adhesive is in full complianceUV/Visible/LED light cureISO 10993 compliantCompatible with E-Beam, gamma, and EtO sterilizationNo solvents added and single component materials require no mixingSecondary heat-cure capability for shadow areas (some products)See-Cure technology for cure confirmation (some products)Blue or Ultra-Red® fluorescing for quality inspection (some products)
Applications 0
In Vitro Diagnostic DevicesReservoir AssemblyTransducer AssemblyMedical Potting
Cured Mechanical Properties Durometer Hardness
A70
Cured Mechanical Properties Elongation At Break
600 %
Cured Mechanical Properties Test Method For Durometer Hardness
American Society for Testing and Materials (ASTM D2240)
Cured Mechanical Properties Test Method For Elongation At Break
American Society for Testing and Materials (ASTM D638)
Cured Mechanical Properties Test Method For Modulus Of Elasticit
American Society for Testing and Materials (ASTM D638)
Cured Mechanical Properties Test Method For Tensile At Break
American Society for Testing and Materials (ASTM D638)
Features And Benefits 0
Broad Spectrum Light CurableUV LED Curable (385 nm)Moisture ResistantUltra-Red® Fluorescing
Features Features
Broad spectrum light curableUV LED curable (385 nm)Moisture resistantUltra-Red® fluorescing
Other Cured Properties Boiling Water Absorption 2 Hours H
1.5 %
Other Cured Properties Glass Transition Tg
57 ºC
Other Cured Properties Linear Shrinkage
2.3 %
Other Cured Properties Refractive Index At 20 Degree Celsius C T
1.49
Other Cured Properties Test Method For Boiling Water Absorption
American Society for Testing and Materials (ASTM D570)
Other Cured Properties Test Method For Glass Transition Tg
American Society for Testing and Materials (ASTM D5418)
Other Cured Properties Test Method For Linear Shrinkage
American Society for Testing and Materials (ASTM D2566)
Other Cured Properties Test Method For Refractive Index At 20 De
American Society for Testing and Materials (ASTM D542)
Other Cured Properties Test Method For Water Absorption 25 Degre
American Society for Testing and Materials (ASTM D570)
Other Cured Properties Water Absorption 25 Degree Celsius C Temp
1.0 %
Properties Modulus Of Elasticity
8.8 MPa | 1,270 psi
Properties Tensile At Break
4.1 MPa | 600 psi
Recommended Curing Equipment 0
Spot LampLED Curing - BlueWave® MX-150Wavelength (PrimeCure®) - 385 nmBroad Spectrum - BlueWave® 200Flood LampLED Curing - BlueWave® AX-550Wavelength (PrimeCure®) - 385 nmBroad Spectrum - 5000-ECEConveyorLED Curing - UVCS with BlueWave® AX-550Wavelength (PrimeCure®) - 385 nmBroad Spectrum - UVCS Conveyor with Fusion F300S
Specifications Biocompatibility
ISO 10993-5 Cytotoxicity
Specifications Cured Durometer Hardness
A70
Specifications Cured Elongation At Break
600 %
Specifications Nominal Viscosity
1,100 cP
Specifications Recommended Substrates
Acrylonitrile Butadiene Styrene (ABS) | Cyclo Olefin Copolymer (COC) | Cyclo Olefin Polymer (COP) | Polycarbonate (PC) | Polymethyl methacrylate (PMMA) | Polyvinyl chloride (PVC)
Substrate Bonding Guide Recommended Adhesives
Acrylonitrile-Butadiene-Styrene (ABS) | Aluminum (AL) | Ceramic (CER) | Cyclo Olefin Copolymer (COC) | Cyclo Olefin Polymer (COP) | Eva Ethylene-Vinyl Acetate (EVA) | Glass: Borosillicate, Quartz, and Mica (Limited Applications) | Polyamide (PA) | Polycarbonate (PC) | Polycyclohexylene Dimethylene (PCTG) | Polyether Block Amide (PEBA) | Polyetherimide (PEI) | Polyethylene Terephthalate (PET) | Polyethylene Terephthalate Glycol (PETG) | Polyimide (PI) (Limited Applications) | Polymethyl Methacrylate (PMMA) | Polystyrene (PS) | Polysulfone (PSU) | Polyurethane (PU) (Limited Applications) | Polyvinyl Chloride (PVC) | Stainless Steel (SS) | Styrene-Acrylonitrile (SAN) | Terephthalateglycol | Thermoplastic Polyurethane (TPU)
Uncured Properties Chemical Class
Acrylated Urethane
Uncured Properties Density
1.01 g/ml
Uncured Properties Shelf Life At 1 To 5 Degree Celsius C Tempera
12 months
Uncured Properties Soluble In
Organic Solvents
Uncured Properties Solvent Content
No Nonreactive Solvents
Uncured Properties Test Method For Density
American Society for Testing and Materials (ASTM D1875)
Uncured Properties Test Method For Nominal Viscosity
Dymax® Standard Test Method (DSTM 502)
Uncured Properties Uncured Appearance
Colorless Translucent Liquid
