Dymax Micro-Dot Dispenser
Dymax Micro-Dot Dispenser
SKU:ADH-025232
Precision and repeatability in adhesive dispensing with the Dymax Micro-Dot Manual Syringe Dispenser.
Regular price
$249.99
Regular price
Sale price
$249.99
Unit price
per
Initiate Order
Dymax Micro-Dot Dispenser
$249.99
Quantity: 1
Claim Your Seller Account
Dymax Micro-Dot Dispenser
$249.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dymax Micro-Dot Manual Syringe Dispenser offers precision and repeatability in adhesive dispensing. This thumb-activated, portable device ensures accurate dispense volumes ranging from 20 microliters to 0.170 mL. With compatibility for 3mL, 5mL, and 10mL syringes, this dispenser provides control over material contamination and allows for easy product changeovers. Ideal for institutional applications, this dispenser meets stringent quality standards and offers a 1-year warranty for guaranteed performance.
Product Specifications
Accessories 0
Item # - T15466Inclined Syringe StandSyringe Stand for One SyringeStands for dispensing syringes and spray guns are ideal for keeping surfaces clean and organized.
Benefits 0
Control over dispense volume, assuring an accurate dispense despite viscosity and syringe level changesUseful for a variety of applicationsPortable; can be used anytime, anywhereEasy product change overEliminates the risk of material contamination during dispenseWorks with standard machine-ready syringesMultiple options for hand-held dispensing
Features 0
Positive-displacement dispensing with adjustable strokePortable design; no power or air requiredDisposable fluid reservoir for no material contaminationCompatible with standard machine-ready syringes (3,5, & 10 mL)
Specifications Activation
Manual by lever or thumb actuator
Specifications Dispenser Type
Manual, positive displacement syringe dispenser
Specifications Height
2.13 in | 5.4 mm
Specifications Length
4.5 in | 11.4 mm
Specifications Material Viscosity
400 cP
Specifications Maximum Shot Size
0.170 mL
Specifications Maximum Tip Taper Size
14 gauge
Specifications Minimum Shot Size
0.0003 mL
Specifications Minimum Tip Taper Size
25 gauge
Specifications Syringe Size
3 mL | 5 mL | 10 mL
Specifications Type
Thumb Activated
Specifications Warranty
1 Year from Purchase
Specifications Weight
2.8 oz | 81.3 g
Specifications Width
0.87 in | 2.2 mm
