Dymax Model 826 Pinch Valve System
Dymax Model 826 Pinch Valve System
SKU:ADH-572ed1
The Dymax Model 826 Pinch Valve System ensures precise dispensing of thick materials while maintaining contamination-free operations.
Regular price
$199.99
Regular price
Sale price
$199.99
Unit price
per
Initiate Order
Dymax Model 826 Pinch Valve System
$199.99
Quantity: 1
Claim Your Seller Account
Dymax Model 826 Pinch Valve System
$199.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Dymax Model 826 Pinch Valve System is engineered for dispensing thicker materials with precision. Featuring lockable controls for flow rate adjustment, tube closure, and suck back, this system ensures a contaminate-free dispensing process. With a disposable fluid path enabling rapid material changeover and preventing air entrapment, it offers shot-to-shot consistency and extends tubing life, making it ideal for institutional use. Compatible with various fluid packages, it excels in automated systems, meeting European Conformity standards.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Accessories 0
Item # - T15451Description - Valve Mounting Assembly
Benefits 0
Fluids remain contaminate free during dispensingPrevents air entrapment during the dispensing process Allows for easy product changeover with minimal cleanup Fluid never comes in contact with the valveâs inner components, reducing valve maintenance and extending the life of the valvePrevents tubing damage, allowing users to secure millions of cycles from the tubing before replacement is requiredShot-to-shot consistency (when used with the DVC-345 Digital Valve Controller)Eliminates drooling and filming over of the nozzle for a clean, drop free dispense when dispensing thin or stringy materialsCompatible with most standard fluid packages and delivery systemsEasy to handle and mount in automated or bench-top systems
Features 0
Disposable fluid path that carries materials from the material reservoir to the dispense tipOver pinch adjustmentStroke adjustment for precise, micrometer control over dispensing volumesAble to dispense from pressurized cartridges, bottles, and pails (requires appropriate reservoir hardware)Lightweight
Parts Description 0
T11146 : DVC-345 digital valve controller | T15279 : Lab Stand - 24 in [60.96 cm] | T15449 : Lab Stand - 8 in [20.32 cm] with Mounting Rods | T15494 : Black Polyethylene Tubing, 0.25 in [0.63 cm] Outer Diameter | T15736 : Black Male Luer Barb | T16307 : Filter Regulator | T16629 : High Precision Regulator
Specifications Activation
3-Way Solenoid Valve | DVC-345 Valve Controller
Specifications Construction Materials
Anodized Aluminum
Specifications Industry Standards
European Conformity
Specifications Maximum Inlet Fluid Pressure
100 psi | 6.9 bar
Specifications Maximum Operating Temperature
150 ºF | 65 ºC
Specifications Maximum Tubing Outer Diameter Od
0.25 in | 0.63 cm
Specifications Operating Air Pressure
60 to 90 psi | 4.1 to 6.3 bar
Specifications Type
No Reservoir
Specifications Valve Depth
1.125 in | 2.86 cm
Specifications Valve Height
1.125 in | 2.86 cm
Specifications Valve Type
Pneumatic Pinch, Normally Closed
Specifications Valve Width
3.75 in | 9.53 cm
Specifications Warranty
1 Year from Purchase Date
System Includes 0
All systems includeModel 826 Valve With 0.25â OD PE TubingSelected ReservoirFluid Line KitsStandAir Precision RegulatorAir Line KitsAir Filter/RegulatorTip Kit
