E-Trac 6 24 Inch Bottom Vertical Curve Conveyor
E-Trac 6 24 Inch Bottom Vertical Curve Conveyor
SKU:OVE-865379
Durable steel bottom vertical curve conveyor with 24" radius & 60º angle, supports up to 1000 lbs, powder coated for longevity. Ideal for overhead conveyors.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
E-Trac 6 24 Inch Bottom Vertical Curve Conveyor
$299.99
Quantity: 1
Claim Your Seller Account
E-Trac 6 24 Inch Bottom Vertical Curve Conveyor
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The E-Trac 6 24 Inch Bottom Vertical Curve Conveyor is designed to efficiently handle elevation changes in conveyor systems. Made of durable 3/16-inch steel, this curved section with a 24-inch radius and 60-degree angle can support loads up to 1000 lbs. The powder-coated finish ensures longevity and protection against corrosion. Ideal for overhead conveyors, this conveyor segment by Richards-Wilcox guarantees smooth vertical transitions, enhancing operational efficiency for both consumer and institutional applications.
Product Specifications
Technical Specs Angles
60 º
Technical Specs Brand Equivalents
Richards-Wilcox
Technical Specs Load Capacity
1000 lb
Technical Specs Material
Steel
Technical Specs Powder Coated
Yes
Technical Specs Product Line
E-Trac 6
Technical Specs Radius
24 in
Technical Specs Thickness
3/16 in
Technical Specs Weight
16 lb
