Eaton-Airflex 8CB250 Tapered Bushing Arrangement
Eaton-Airflex 8CB250 Tapered Bushing Arrangement
SKU:CLU-e5ab9f
Dependable Eaton-Airflex 8CB250 Tapered Bushing Arrangement for high-speed, cyclic operations with precise clutch and brake capabilities.
Regular price
$1,899.99
Regular price
Sale price
$1,899.99
Unit price
per
Initiate Order
Eaton-Airflex 8CB250 Tapered Bushing Arrangement
$1,899.99
Quantity: 1
Claim Your Seller Account
Eaton-Airflex 8CB250 Tapered Bushing Arrangement
$1,899.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Eaton-Airflex 8CB250 Tapered Bushing Arrangement, part of the CB Clutches and Brakes series, is expertly crafted to deliver reliable performance in the most demanding industrial settings. Ideal for high-speed operations and power transmission, this assembly guarantees precise clutch and brake functionality. With dimensions meeting stringent specifications, including a Spider Shaft Diameter range of 1.250 thru 2.000 and Air Applied actuation, this arrangement ensures efficiency and durability.
Product Specifications
Specifications Actuation
Air Applied
Specifications Bolt Hole Size L
0.406 in | 10.3 mm
Specifications Dimension D
9.63 in | 245 mm
Specifications Dimension D1
2.69 in
Specifications Dimension D3
0.28 in
Specifications Dimension D37
2.4 in | 31 mm
Specifications Dimension D38
2.7 in | 69 mm
Specifications Dimension D47
2.50 in
Specifications Dimension M
1.38 in
Specifications Dimension X
4.06 in | 103 mm
Specifications Hub Shaft Diameter
1.250 thru 2.000
Specifications Manufacturer
Eaton-Airflex
Specifications Size
8CB250
Specifications Spider Shaft Diameter
1.250 thru 2.000
