Eaton-Airflex 8CB250 Tapered Bushing Clutch/Brake Assembly
Eaton-Airflex 8CB250 Tapered Bushing Clutch/Brake Assembly
SKU:CLU-fbd787
Dependable and high-performance Eaton-Airflex 8CB250 Tapered Bushing Clutch/Brake Assembly for industrial applications.
Regular price
$899.99
Regular price
Sale price
$899.99
Unit price
per
Initiate Order
Eaton-Airflex 8CB250 Tapered Bushing Clutch/Brake Assembly
$899.99
Quantity: 1
Claim Your Seller Account
Eaton-Airflex 8CB250 Tapered Bushing Clutch/Brake Assembly
$899.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Eaton-Airflex 8CB250 Tapered Bushing Clutch/Brake Assembly is expertly crafted for dependable performance in demanding industrial applications. With a torque rating of up to 4290 lb-in at 75 psi, it excels in high-speed operations and power transmission tasks. This assembly, designed by Eaton-Airflex, offers precise actuation through air applied mechanisms, ensuring reliability and efficiency. From its durable construction to its compatibility with various shaft diameters, this product meets the rigorous standards of industrial and government procurement requirements.
Product Specifications
Specifications Actuation
Air Applied
Specifications Air Inlet Thread
3/8-18 in
Specifications Bolt Hole Size L
0.406 in | 10.3 mm
Specifications Dimension D
6.78 in | 172 mm
Specifications Dimension D2
2.94 in | 75 mm
Specifications Dimension D24
1.56 in | 40 mm
Specifications Dimension D37
2.0 in | 51 mm
Specifications Dimension D38
1.1 in | 28 mm
Specifications Dimension H
10.75 in | 273 mm
Specifications Dimension H10
3.500 in | 108.0 mm
Specifications Dimension H9
4.250 in | 108.0 mm
Specifications Dimension O
1/4-18 in
Specifications Dimension X
4.00 in | 102 mm
Specifications Manufacturer
Eaton-Airflex
Specifications Minimum P
6.69 in | 170 mm
Specifications Number Of Mounting Holes
8
Specifications Shaft Diameter For Spider Or Drum
1.250 thru 2.000
Specifications Size
8CB250
Specifications Torque Rating At 52 Bar
485 Nm
Specifications Torque Rating At 75 Psi
4290 lb·in
