EB Series Encapsulated 2-way Ball Valves - Alloy C-276
EB Series Encapsulated 2-way Ball Valves - Alloy C-276
SKU:VAL-ba4c8a
Upgrade to EB Series Encapsulated 2-way Ball Valves for precision fluid control. Alloy C-276 construction, Cv: 0.75, modified PTFE packing, and durable yellow Nylon handle with SS insert.
Regular price
$69.99
Regular price
Sale price
$69.99
Unit price
per
Initiate Order
EB Series Encapsulated 2-way Ball Valves - Alloy C-276
$69.99
Quantity: 1
Claim Your Seller Account
EB Series Encapsulated 2-way Ball Valves - Alloy C-276
$69.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your industrial fluid control system with precision and reliability using our EB Series Encapsulated 2-way Ball Valves. Crafted from Alloy C-276, these valves feature 1/4-18 MNPT and 1/4 in Duolok Tube Fitting connections, with a Cv of 0.75. The modified PTFE packing ensures leak-free operation, while the yellow Nylon handle with Stainless Steel insert offers durability. With a working pressure of 3000 psig and a temperature range of -65 to 300°F, these valves deliver optimal performance in challenging environments. Trust in our EB Series for superior quality and efficiency.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions A
2.20 in | 55.9 mm
Dimensions B
1.20 in | 30.5 mm
Dimensions D
0.44 in | 11.2 mm
Dimensions E
0.38 in | 9.7 mm
Dimensions F
1.43 in | 36.3 mm
Dimensions G
3/16 in | 4.8 mm
Dimensions H
25/32 in | 19.8 mm
Dimensions J
1.53 in | 38.8 mm
Dimensions W
0.78 in
Specifications Actuation Type
.
Specifications Body Material
Alloy C-276
Specifications Brand Series
EB Series
Specifications Connection 1 Size
1/4-18
Specifications Connection 1 Type
MNPT
Specifications Connection 2 Size
1/4 in
Specifications Connection 2 Type
Duolok Tube Fitting
Specifications Cv
0.75
Specifications Handle Color
Yellow
Specifications Handle Type
Nylon - Stainless Steel Insert
Specifications Hardware
.
Specifications Orifice
0.187 in | 4.7498 mm
Specifications Packing Material
Modified PTFE
Specifications Production Category
4
Specifications Shape
2-way
Specifications Temperature
-65 to 300 ºF | -53 to 148 ºC
Specifications Working Pressure
3000 psig | 206 bar
