ECF561E Henkel/Ablestik Frozen Epoxy Adhesive
ECF561E Henkel/Ablestik Frozen Epoxy Adhesive
SKU:PRE-19af5f
High-performance electrically conductive frozen epoxy adhesive for precise bonding with excellent thermal and electrical conductivity.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
ECF561E Henkel/Ablestik Frozen Epoxy Adhesive
$39.99
Quantity: 1
Claim Your Seller Account
ECF561E Henkel/Ablestik Frozen Epoxy Adhesive
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The ECF561E Henkel/Ablestik Pre-Form Frozen Epoxy is a high-performance electrically conductive die attach adhesive designed for bonding materials with severe mismatches in coefficients of thermal expansion. It features excellent electrical and thermal conductivity, is electrically conductive in x, y, and z axes, and exhibits low squeeze-out during bonding. With a quick 30-minute cure schedule at 150°C, this adhesive ensures efficient substrate bonding and acts as an electrical ground plane. Precision-cut and drilled to tight tolerances, these frozen epoxy pre-forms are expertly supplied by Accumet Engineering for optimal performance in various applications.
Product Specifications
Additional Information Additional Information
The 5025E series has excellent electrical and thermal conductivity, is electrically conductive in x, y, z axes, and exhibits very low squeeze-out during bonding. The typical cure schedule is only 30 minutes at 150ºC.Accumet's frozen epoxy pre-forms can be professionally supplied to be ready to use, as we are experts in laser cutting and drilling all materials to incredibly tight tolerances. All of our frozen epoxy pre-forms are stocked and supplied from one or both of our service centers in Westford, MA and Hudson, MA. We ship throughout the US, and we will work with you hands-on from prototyping to full production runs, to ensure you get the most optimally prepared pre-form - every time.
Features Features
Good Electrical PropertiesElectrically Conductive
Technical Specs Brands
Accumet Engineering
Technical Specs Heat Curing At 150 Degree Celsius C Temperature
1 h
Technical Specs Note For Shelf Life Sl At 50 Percent Fro
Maintained at -40°C
Technical Specs Shelf Life Sl At 50 Percent From Noted
1 y
Technical Specs Thermal Conductivity
121 ºC | 1.6 W/m·K
Technical Specs Thicknesses Available
0.004
