Economical Hand Operated Hydraulic Pump - PS Series
Economical Hand Operated Hydraulic Pump - PS Series
SKU:HYD-0df194
An economical and durable hand-operated hydraulic pump with a 5000 PSI maximum pressure rating. Ideal for various applications.
Regular price
$243.00
Regular price
Sale price
$243.00
Unit price
per
Initiate Order
Economical Hand Operated Hydraulic Pump - PS Series
$243.00
Quantity: 1
Claim Your Seller Account
Economical Hand Operated Hydraulic Pump - PS Series
$243.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PS Series Hand Operated Hydraulic Pump offers exceptional value with its economical yet high-quality design. This compact pump features a steel pump body and a hard chrome plated piston, ensuring durability and reliability. With a maximum pressure rating of 5000 PSI, it is suitable for various applications. The pump comes with a 24" lever for easy operation. While being cost-effective, this pump maintains the same quality components as other Star pumps, making it a practical choice for both consumer and institutional buyers.
Product Specifications
Specifications Adjustable Overload Relief Valve
No
Specifications Body Material
Steel
Specifications Inlet Port Size Nptf
1/4
Specifications Lever Load Per 1000 Psi
19.0 lb
Specifications List Price
243 USD
Specifications Manual Pressure Release Valve
No
Specifications Maximum Pressure Rating
5000 psi
Specifications Net Weight
6 lb
Specifications Oil Reservoir
false
Specifications Outlet Port Size Nptf
1/4
Specifications Piston
Hard Chrome Plated
Specifications Piston Diameter
5/8 in
Specifications Series
PS
Specifications Volume Per Stroke
0.30 in³
Technical Information 0
Limited WarrantyAll Star pumps are covered by a limited warranty on materials and workmanship for one year from the date of manufacture. Star will repair or replace at its option any pump in which Star finds manufacturing defects. In order to get warranty service a pump must be returned to the Star plant freight prepaid with a written explanation of the problem.Technical DataLight hydraulic oil is recommended for use with Star pumps. Oils with SUS viscosity of 75 to 150 at 100 degrees Fahrenheit will give satisfactory performance (ISO grade 15, 22, or 32). In an emergency situation when the above oils are not available, use 5 W or 10 W motor oil or automatic transmission fluid.All exposed surfaces of standard Star pumps are painted with one coat of industrial quality paint. Pumps painted with special colors with two coat finishes, or with prime coat only, and pumps with special plated or polished parts, are also available.
