The Embossed Aluminum Tread Sheet and Plate in 3003-H22 grade offers superior strength with excellent corrosion resistance, making it ideal for applications such as cooking utensils, decorative trim, and chemical equipment. With a thickness of 0.125 inches and a size of 48 x 192 inches, this aluminum plate boasts remarkable workability and can be deep drawn, spun, welded, or brazed. Its bright finish adds to its aesthetic appeal, while the 123.65 lbs weight per plate ensures durability in various settings.
Product Specifications
Aluminum Alloy Designations 0
The aluminum industry uses a four-digit index system for the designation of its wrought aluminum alloys.As outlined below, the first digit indicates the alloy group according to the major alloying elements.1xxx SeriesIn this group minimum aluminum content is 99% and there is no major alloying element. The second digit indicates modifications in impurity limits. If the second digit is zero, there is no special control on individual impurities. Digits 1 through 9, which are assigned consecutively as needed, indicate special control of one or more individual impurities. The last two digits indicate specific minimum aluminum content. Although the absolute minimum aluminum content in this group is 99%, the minimum for certain grades is higher than 99%, and the last two digits represent the hundredths of a per cent over 99. Thus, 1030 would indicate 99.30% minimum aluminum. without special control on individual impurities. The designations 1130, 1230, 1330, etc.. indicate the same purity with special control on one or more impurities. Likewise 1100 indicates minimum aluminum content of 99.00% with individual impurity control.2xxx through 9xxx SeriesThe major alloying elements are indicated by the first digit, as follows: 2xxx Copper3xxx Manganese4xxx Silicon5xxx Magnesium6xxx Magnesium and silicon7xxx Zinc8xxx Other element9xxx Unused seriesThe second digit indicates alloy modification. If the second digit is zero. it indicates the original alloy: digits 1 through 9, which are assigned consecutively, indicate alloy modifications. The last two digits have no special significance, serving only to identify the different alloys in the group.Experimental AlloysExperimental alloys are designated according to the four digit system, but they are prefixed by the letter X. The prefix is dropped when the alloy becomes standard. During development, and before they are designated as experimental, new alloys are identified by serial numbers assigned by their originators. Use of the serial number is discontinued when the X number is assigned.
Specifications Density
0.099 lbs/in³
Specifications Finish
Bright
Specifications Grade
3003
Specifications Length
192
Specifications Material
Aluminum
Specifications Series
3003-H22
Specifications Shapeform
Plates
Specifications Size
48 x 192
Specifications Specific Gravity
2.73
Specifications Temper
H22
Specifications Thickness
0.125 inches | 3.125 mm
Specifications Weight Per Plate
123.65 lbs | 56.01345 kg
Specifications Width
48
