EMI Shielding Composite with 1.53 Specific Gravity
EMI Shielding Composite with 1.53 Specific Gravity
SKU:HEA-31226e
Advanced EMI shielding composite with 1.53 Specific Gravity for superior heat sink properties and EMI protection.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
EMI Shielding Composite with 1.53 Specific Gravity
$129.99
Quantity: 1
Claim Your Seller Account
EMI Shielding Composite with 1.53 Specific Gravity
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Introducing our cutting-edge EMI shielding composite with a specific gravity of 1.53. Designed to meet the high heat sink/EMI shield demands in various applications like Lamp/ECU/HPCU/Wireless charger housings and vehicle radars. Our composite offers impressive conductive properties comparable to Al die-casting products, adjustable EMI shielding effectiveness, superior lightweight design (40-55% weight reduction), and high compatibility compared to traditional metals. Tested to ASTM standards for specific gravity, tensile strength, flexural strength, modulus, Izod impact, and thermal conductivity, ensuring top-notch performance and reliability.
Product Specifications
Additional Information
CNT is known as having excellent electrical conductivity, thermal conductivity, strength, and thermal stability. Demand for Li-ion Battery as positive electrode conductive additives has been increasing and CNT is also being used in applications such as tire treads and antistatic resins.Kumho's CNT have a highly oriented bundle structure and have been used by major battery manufacturers and tire manufacturers globally. Multiple grades of CNT are available depending on required property and each application, and we also have various types of rubber and resin compound and masterbatches.Kumho Petrochemical with one of the world's largest synthetic rubber manufacturing capacities was established in 1970 and developing their business in several fields including synthetic resins, specialty chemicals, nanocarbons, energy, and building materials.Major application with Kumho's CNTLi-ion Battery as positive electrode conductive additives for automotiveTire treadsElectronic Parts TraysConductive coatingElectro-Magnetic Interference (EMI) Shielding CompositeConductive resin/rubber
Properties Flexural Modulus 5 Millimeter Mmminitue Min
195,000 kgf/cm²
Properties Flexural Strength 5 Millimeter Mmminitue Min
1,220 kgf/cm²
Properties Izod Impact Notched 32 Millimeter Mm
3.8 kgf·cm/cm
Properties Specific Gravity
1.53
Properties Tensile Strength 5 Millimeter Mmminitue Min
755 kgf/cm²
Properties Test Method For Flexural Modulus 5 Millimeter
American Society for Testing and Materials (ASTM) D790
Properties Test Method For Flexural Strength 5 Millimete
American Society for Testing and Materials (ASTM) D790
Properties Test Method For Izod Impact Notched 32 Millim
American Society for Testing and Materials (ASTM) D256
Properties Test Method For Specific Gravity
American Society for Testing and Materials (ASTM) D792
Properties Test Method For Tensile Strength 5 Millimeter
American Society for Testing and Materials (ASTM) D638
Properties Test Method For Thermal Conductivity
American Society for Testing and Materials (ASTM) D5470
Properties Thermal Conductivity
>10 W/m·K
