Euroboor Automatic Magnetic Drill Press
Euroboor Automatic Magnetic Drill Press
SKU:ELE-d02f37
Enhance productivity with the Euroboor Automatic Magnetic Drill Press - the pinnacle of technology for efficient drilling, tapping, and threading operations.
Regular price
$2,499.99
Regular price
Sale price
$2,499.99
Unit price
per
Initiate Order
Euroboor Automatic Magnetic Drill Press
$2,499.99
Quantity: 1
Claim Your Seller Account
Euroboor Automatic Magnetic Drill Press
$2,499.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Euroboor Automatic Magnetic Drill Press is a cutting-edge solution for efficient drilling, tapping, threading, and countersinking tasks. Equipped with a self-feed system and intelligent electronics, this machine offers unparalleled stability and functionality. With automatic return features and high precision slide & rail construction, it ensures maximum drilling speed and increased cutter lifetime. Boost productivity and cost savings with this innovative drilling solution.
Product Specifications
Features Features
Full automatic drillingHigh precision slide & rail constructionIntegrated oil bath gearboxMorse Taper 3 spindleExternal access to carbon brushesDigital read - outIntelligent electronics combine maximum drilling speed with increased cutter lifetime
Technical Specs Annular Cutters Diameter
1/2 to 2-3/16 in
Technical Specs Annular Cutters Material
Mild Steel
Technical Specs Brands
Euroboor
Technical Specs Countersinking Diameter
3/8 to 1-9/16 in
Technical Specs Frequency
50 to 60 Hz
Technical Specs Height
19-5/16 to 26 in
Technical Specs Length
13-9/16 in
Technical Specs Magnetic Force
4100 lb
Technical Specs Magnet Height
1-7/8 in
Technical Specs Magnet Length
6-11/16 in
Technical Specs Magnet Width
3-3/8 in
Technical Specs Motor Power
14.5 A
Technical Specs Mt3 Weldon Spindle
3/4 in
Technical Specs Speed Load
100 to 500 rpm | 60 to 175 rpm
Technical Specs Speed No Load
100 to 500 rpm | 60 to 275 rpm
Technical Specs Stroke
6-11/16 in
Technical Specs Threading
3/8 to 19/16 in
Technical Specs Total Power
15.6 A
Technical Specs Twist Drills Diameter
1/16 to 15/16 in
Technical Specs Voltage
110 to 120 V | 220 to 240 V
Technical Specs Weight
35 lb
Technical Specs Width
12 in
