Eurovalve EVFS DN125 Double Flanged DIN Butterfly Valve
Eurovalve EVFS DN125 Double Flanged DIN Butterfly Valve
SKU:VAL-64db43
Reliable Eurovalve EVFS DN125 Double Flanged DIN Butterfly Valve for isolating and regulating functions with PN16 standard flange connections. Durable Ductile Iron body and NBR liner for tight shut-off.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
Eurovalve EVFS DN125 Double Flanged DIN Butterfly Valve
$299.99
Quantity: 1
Claim Your Seller Account
Eurovalve EVFS DN125 Double Flanged DIN Butterfly Valve
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Eurovalve EVFS DN125 Double Flanged DIN Butterfly Valve is a versatile and durable valve suitable for both isolating and regulating functions. With flange connections conforming to PN16 standards, this valve offers a sturdy build with Ductile Iron body material and a Stainless Steel shaft. The Nitrile Butadiene Rubber liner ensures tight shut-off, while the bare shaft allows for manual operation. Approved by ABS, DNV, and other notable bodies, this valve meets stringent industry standards for reliability and performance.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications A
125 mm
Specifications Actuation Possibilities
Bare
Specifications Available Type Approvals
ABS | BV | DNV | DVGW | FM | GL | KIWA | LRS | NKK | RIN | RMRS | SVGW | WRC
Specifications Body Material
Ductile Iron
Specifications C
140 mm
Specifications D
109 mm
Specifications E
160 mm
Specifications F
12 mm
Specifications Flange Connections
PN 16
Specifications G
34 mm
Specifications H Diameter
12 mm
Specifications Iso 5211
F07
Specifications K
70 mm
Specifications L
90 mm
Specifications Liner Material
Nitrile Butadiene Rubber (NBR)
Specifications M Diameter
9 mm
Specifications N Number Of Holes
4
Specifications Shaft Material
Stainless Steel 1.4057
Specifications Size
DN125 - 5" | 125 mm
Specifications Standard
DIN
Specifications Stem Material
Aluminum Bronze | Duplex Stainless Steel 1.4462 | Martensitic Stainless Steel 1.4408
Specifications Valve Function
Isolating valve (on,off) and regulating valve | Regulating valve
Specifications Valve Shut Off Pressure
10 bar | 16 bar | 2.5 bar | 6 bar
Specifications Weight
17.0 kg
