Eurovalve Series EVFS Lever Operated Cast Iron Butterfly Valve

Name: Eurovalve Series EVFS Lever Operated Cast Iron Butterfly Valve
Brand: World Wide Metric, Inc.
SKU: VAL-4a2a7b
Price: 299.99 USD
Availability: OutOfStock

SKU:VAL-4a2a7b

Premium Eurovalve Series EVFS Cast Iron Butterfly Valve, ideal for precise flow control in industrial settings.

$299.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Eurovalve Series EVFS Lever Operated Cast Iron Butterfly Valve is a high-quality, durable valve designed for both isolating and regulating flow with ease. Constructed from robust materials such as GG25 Cast Iron and Stainless Steel, this valve ensures reliable performance under varying pressures. With ISO 5211 mounting pad for easy actuation and EPDM liner for enhanced sealing, it meets stringent DIN standards for quality and performance. Ideal for industrial applications requiring precision control and durability.

Product Specifications

Specifications A

50 mm

Specifications Actuation Possibilities

Lever

Specifications Available Type Approvals

ABS | BV | DNV | DVGW | FM | GL | KIWA | LRS | NKK | RIN | RMRS | SVGW | WRC

Specifications Body Material

Cast Iron

Specifications C

108 mm

Specifications D

63 mm

Specifications E

118 mm

Specifications F

12 mm

Specifications Flange Connections

PN 6

Specifications G

34 mm

Specifications H Diameter

10 mm

Specifications Iso 5211

F07

Specifications K

70 mm

Specifications L

90 mm

Specifications Liner Material

Ethylene Propylene Diene Monomer (EPDM)

Specifications M Diameter

9 mm

Specifications N Number Of Holes

Specifications Pressure

PN 6

Specifications Shaft Material

Stainless Steel 1.4462

Specifications Size

DN50 - 2" | 50 mm

Specifications Standard

DIN

Specifications Stem Material

Aluminum Bronze | Duplex Stainless Steel 1.4462 | Martensitic Stainless Steel 1.4408

Specifications Valve Function

Isolating valve (on,off) and regulating valve | Regulating valve

Specifications Valve Shut Off Pressure

10 bar | 16 bar | 2.5 bar | 6 bar

Specifications Weight

8.0 kg

Eurovalve Series EVFS Lever Operated Cast Iron Butterfly Valve
