Eurovalve Series EVFS Lever Operated Cast Iron DIN Butterfly Valve
Eurovalve Series EVFS Lever Operated Cast Iron DIN Butterfly Valve
SKU:VAL-516bb6
Premium Eurovalve Series EVFS Butterfly Valve, DN125, PN6, for precise control and durability
Regular price
$599.99
Regular price
Sale price
$599.99
Unit price
per
Initiate Order
Eurovalve Series EVFS Lever Operated Cast Iron DIN Butterfly Valve
$599.99
Quantity: 1
Claim Your Seller Account
Eurovalve Series EVFS Lever Operated Cast Iron DIN Butterfly Valve
$599.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Eurovalve Series EVFS Lever Operated Cast Iron DIN Butterfly Valve is designed for precision control and durable performance. With a size of DN125 (5") and PN6 pressure rating, this valve offers reliable isolating and regulating functions. Crafted with high-quality materials including GG25 Cast Iron body, EPDM liner, and Stainless Steel shaft, it ensures long-lasting efficiency in various industrial applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications A
125 mm
Specifications Actuation Possibilities
Lever
Specifications Available Type Approvals
ABS | BV | DNV | DVGW | FM | GL | KIWA | LRS | NKK | RIN | RMRS | SVGW | WRC
Specifications Body Material
Cast Iron
Specifications C
140 mm
Specifications D
109 mm
Specifications E
160 mm
Specifications F
12 mm
Specifications Flange Connections
PN 6
Specifications G
34 mm
Specifications H Diameter
12 mm
Specifications Iso 5211
F07
Specifications K
70 mm
Specifications L
90 mm
Specifications Liner Material
Ethylene Propylene Diene Monomer (EPDM)
Specifications M Diameter
9 mm
Specifications N Number Of Holes
4
Specifications Pressure
PN 6
Specifications Shaft Material
Stainless Steel 1.4462
Specifications Size
DN125 - 5" | 125 mm
Specifications Standard
DIN
Specifications Stem Material
Aluminum Bronze | Duplex Stainless Steel 1.4462 | Martensitic Stainless Steel 1.4408
Specifications Valve Function
Isolating valve (on,off) and regulating valve | Regulating valve
Specifications Valve Shut Off Pressure
10 bar | 16 bar | 2.5 bar | 6 bar
Specifications Weight
17.0 kg
