EVFS Double Flanged Ductile Iron Butterfly Valve
EVFS Double Flanged Ductile Iron Butterfly Valve
SKU:VAL-4da1c2
Premium DN50 PN16 Ductile Iron Butterfly Valve for reliable industrial operations.
Regular price
$289.99
Regular price
Sale price
$289.99
Unit price
per
Initiate Order
EVFS Double Flanged Ductile Iron Butterfly Valve
$289.99
Quantity: 1
Claim Your Seller Account
EVFS Double Flanged Ductile Iron Butterfly Valve
$289.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The EVFS Double Flanged Ductile Iron Butterfly Valve is a high-performance valve designed for industrial applications. With a size of DN50 (2") and PN16 pressure rating, this valve offers reliable isolating and regulating functions. Crafted with Ductile Iron body, Stainless Steel shaft, and EPDM liner, it ensures durability and corrosion resistance. Compliant with DIN standards and approved by ABS, BV, DNV, and more, this valve guarantees quality and reliability in diverse environments.
Product Specifications
Specifications A
50 mm
Specifications Actuation Possibilities
Bare
Specifications Available Type Approvals
ABS | BV | DNV | DVGW | FM | GL | KIWA | LRS | NKK | RIN | RMRS | SVGW | WRC
Specifications Body Material
Ductile Iron
Specifications C
108 mm
Specifications D
63 mm
Specifications E
118 mm
Specifications F
12 mm
Specifications Flange Connections
PN 16
Specifications G
34 mm
Specifications H Diameter
10 mm
Specifications Iso 5211
F07
Specifications K
70 mm
Specifications L
90 mm
Specifications Liner Material
Ethylene Propylene Diene Monomer (EPDM)
Specifications M Diameter
9 mm
Specifications N Number Of Holes
4
Specifications Shaft Material
Stainless Steel 1.4462
Specifications Size
DN50 - 2" | 50 mm
Specifications Standard
DIN
Specifications Stem Material
Aluminum Bronze | Duplex Stainless Steel 1.4462 | Martensitic Stainless Steel 1.4408
Specifications Valve Function
Isolating valve (on,off) and regulating valve | Regulating valve
Specifications Valve Shut Off Pressure
10 bar | 16 bar | 2.5 bar | 6 bar
Specifications Weight
8.0 kg
