EXAIR 1114 Super Air Nozzle, High Force Air Nozzle
EXAIR 1114 Super Air Nozzle, High Force Air Nozzle
SKU:HIG-d6ef5f
Enhance productivity & safety with EXAIR 1114 Super Air Nozzle – powerful, quiet, OSHA-compliant blowoff solution
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
EXAIR 1114 Super Air Nozzle, High Force Air Nozzle
$129.99
Quantity: 1
Claim Your Seller Account
EXAIR 1114 Super Air Nozzle, High Force Air Nozzle
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The EXAIR 1114 Super Air Nozzle is engineered to deliver optimized entrained airflow with minimal noise levels, providing a remarkable blowing force of 6.6 lbs (3.01 kg) – over 8 times more than standard nozzles. Crafted from Zinc Aluminum alloy, it features a 1 FNPT inlet and consumes 135 SCFM of compressed air. This powerful yet compact nozzle not only enhances production efficiency and safety but also meets OSHA noise and pressure requirements, reducing compressed air costs significantly. Ideal for air assist, chip removal, part cleaning, cooling, drying, and more.
Product Specifications
Specifications Advantages
10 dBA Average Noise Reduction | Compact | Conserve Compressed Air | Improved Blowoff Performance | Improved Production | Improved Safety | Meets OSHA Noise Level Requirements | Meets OSHA Pressure Requirements | Reduced Compressed Air Cost
Specifications Air Consumption
135 SCFM | 3823 SLPM
Specifications Applications
Air Assist | Chip Removal | Fiber Conveying | Liquid Blowoff | Material Conveying | Part Cleaning | Part Cooling | Part Drying | Part Ejection
Specifications Force
6.6 lb | 3005 g
Specifications Inlet
1 FNPT
Specifications Material
Zinc Aluminum alloy
Specifications Note
Force measured at 12" (305 mm) from target
Specifications Pressure
80 psig | 5.5 bar
Specifications Sound Level
99 dBA
