EXAIR Mini Super Air Nozzle - 1/8 NPT, Zinc Aluminum Alloy

Name: EXAIR Mini Super Air Nozzle - 1/8 NPT, Zinc Aluminum Alloy
Brand: Exair LLC
SKU: AIR-c667d5
Price: 39.99 USD
Availability: OutOfStock

SKU:AIR-c667d5

Upgrade your airflow efficiency with the EXAIR Mini Super Air Nozzle. Delivering high-velocity airflow with low sound levels and reduced air consumption, this nozzle enhances safety and efficiency in diverse applications.

$39.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Upgrade your airflow efficiency with the EXAIR Mini Super Air Nozzle. Crafted from Zinc Aluminum alloy, this nozzle delivers a forceful, concentrated stream of high-velocity airflow while maintaining low sound levels, reduced air consumption, and optimal force. Utilizing the Coanda effect, it amplifies compressed air flow up to 25 times or more, ensuring high-volume, high-velocity air blasts at minimal consumption. With advantages like improved safety, reduced compressed air costs, and OSHA compliance for noise and pressure requirements, this Mini Super Air Nozzle is ideal for various applications, including Air Assist, Chip Removal, and Part Cooling, among others.

Product Specifications

Specifications Advantages

Specifications Air Consumption

10 SCFM | 283 SLPM

Specifications Applications

Specifications Force

9.0 oz | 255 g

Specifications How Air Nozzles Work

Air Nozzles use the Coanda effect to amplify compressed air flow up to 25 times or more. As illustrated on the right, compressed air (black arrows) is ejected through a series of nozzles on the outer perimeter. As the air travels along the outer wall of the nozzle, surrounding air (blue arrows) is entrained into the stream. The airstream that results is a high volume, high velocity blast of air at minimal consumption. The air is always ejected so it can vent safely, well below OSHA dead end pressure requirements, should the nozzle end be blocked.

Specifications Inlet

1/8 FNPT

Specifications Material

Zinc Aluminum alloy

Specifications Note

Force measured at 12" (305 mm) from target

Specifications Pressure

80 psig | 5.5 bar

Specifications Selecting The Right Air Nozzle

EXAIR manufactures a wide selection of Air Nozzles and Jets, which are divided into two groups. The first group includes Air Nozzles and Jets that deliver force up to 22 ounces (624 grams) and are suitable for most applications. The second group includes Air Nozzles that produce high force up to 23 lbs (10.43 kg) where additional reach and force are required.Type 303 Stainless Steel - high temperatures and corrosive environments. Max temp 800°F (426°C)Type 316 Stainless Steel - high temperatures, corrosive environments, and mechanical wear. Max temp 1000°F (538°C)Brass - general purpose applications. Max temp 400°F (204°C)Zinc Aluminum Alloy - general purpose applications. Max temp 250°F (121°C)PEEK - replaces metals in harsh environments. Offers chemical resistance, non-marring. Max temp 320°F (160°C)

Specifications Sound Level

71 dBA
