Extra Fine Tungsten Carbide - Ultra-Met Grade C3/K10

Name: Extra Fine Tungsten Carbide - Ultra-Met Grade C3/K10
Brand: Ultra-Met
SKU: STA-23e3d8
Price: 39.99 USD
Availability: OutOfStock

SKU:STA-23e3d8

High-quality Ultra-Met Grade Tungsten Carbide - ideal for precision machining applications.

$39.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Achieve precision and durability in machining with our Ultra-Met Grade Tungsten Carbide. With 94% Tungsten Carbide and 6% Cobalt composition, this grade boasts a hardness of 92.8 HRA, ensuring quality finishing on various materials. Ideal for light finishing applications on cast iron, non-ferrous, and non-metallic materials, the Ultra-Met Grade C3/K10 offers reliable performance and longevity. Trust in the 360 ksi transverse rupture strength and density of 14.94 g/cc for consistent results in your machining operations.

Product Specifications

Classifications Ansi Code

Classifications Applications

Light Finishing (Machining - Cast Iron, Non-Ferrous, and Non-Metalic Materials)

Classifications Grades

Tungsten Carbide

Classifications Grain Size

Extra Fine

Classifications Iso Code

K10

Nominal Composition Cobalt Co

6.00%

Nominal Composition Tungsten Carbide Wc

94.00%

Physical Properties Density

14.94 g/cc

Physical Properties Hardness Hra

92.8 Ra

Physical Properties Transverse Rupture Trs

360 ksi | 360000 psi

Extra Fine Tungsten Carbide - Ultra-Met Grade C3/K10
