Fe77.5/B15/Si7.5 Iron Alloy Wire
Fe77.5/B15/Si7.5 Iron Alloy Wire
SKU:IRO-91d2a8
High-quality Fe77.5/B15/Si7.5 Iron Alloy Wire for industrial applications. Features excellent electrical, mechanical, and thermal properties.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Fe77.5/B15/Si7.5 Iron Alloy Wire
$39.99
Quantity: 1
Claim Your Seller Account
Fe77.5/B15/Si7.5 Iron Alloy Wire
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Discover the high-quality Fe77.5/B15/Si7.5 Iron/Boron/Silicon Wire, featuring a diameter of 0.0125 mm and a length range of 1 to 50 meters. Ideal for soft magnetic applications, brazing, and coating, this wire offers excellent electrical properties with an electrical resistivity of 124 µΩ·cm and a Curie temperature of 422 ºC. With outstanding mechanical and thermal properties, this metallic glass wire is a top choice for various industrial applications.
Product Specifications
Electrical Properties Electrical Resistivity
124 µΩ·cm
Magnetic Properties Curie Temperature
422 ºC
Material Material
Iron/Boron/SiliconMetallic glasses (glassy alloys) or amorphous metals. Uses include soft magnetic applications, brazing, coating and as reinforcing fibers.
Mechanical Properties Elongation At Break
2.3 %
Mechanical Properties Hardness Vickers
940 Kgf mm-2
Mechanical Properties Tensile Modulus
155.00 GPa
Specifications Diameter
0.0125 mm
Specifications Form
Wire
Specifications Grade
Metallic Glass
Specifications Length
1 to 50 m
Specifications Tolerance For Length Round
-1 mm | +5 mm
Thermal Properties Coefficient Of Thermal Expansion At 20 Degree
8.700 x10-6 K-1
Thermal Properties Crystallization Temperature
553 ºC
Tolerances Disc Diameter Tolerance
10 %
Type Type
GlassGoodfellow offers two distinct types of glass products: The first are generally silica-based, non-crystalline (amorphous) solids which exhibit a glass transition and are brittle and transparent. The properties of glass materials can be readily modified to alter their optical performance and other characteristics. This type is available through Goodfellow's Ceramic and Glass Division. Generally, these products are made to order for customers, so we do not list them in our Catalog. Please contact us with your requirements. The second type of glass product is commonly referred to as "metallic glasses" or "glassy metals". In contrast to crystalline metals and alloys with highly ordered atomic structures, these are non-crystalline (amorphous) metals or, more usually, alloys. Our website details those glassy metals which are available from stock; please contact us if you are unable to find the item you specifically require.
