Fe78/B13/Si9 Iron/Boron/Silicon Foil
Fe78/B13/Si9 Iron/Boron/Silicon Foil
SKU:IRO-49f0b0
High-quality Fe78/B13/Si9 Iron/Boron/Silicon Foil with exceptional performance and compliance for precision applications.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Fe78/B13/Si9 Iron/Boron/Silicon Foil
$39.99
Quantity: 1
Claim Your Seller Account
Fe78/B13/Si9 Iron/Boron/Silicon Foil
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Fe78/B13/Si9 Iron/Boron/Silicon Foil is a high-quality, thin sheet made of metallic glass with a thickness of 0.025mm. Designed for superior performance, it boasts excellent electrical resistivity, magnetic properties, and mechanical strength. With a Curie Temperature of 415°C and a Vickers hardness of 860 Kgf mm-2, this foil is ideal for applications requiring precision and reliability. Compliant with federal procurement standards and industry-specific certifications, this foil meets the stringent requirements of government and institutional buyers.
Product Specifications
Electrical Properties Electrical Resistivity
137 µΩ·cm
Magnetic Properties Coercivity As Cast
14.00 A m-1
Magnetic Properties Curie Temperature
415 ºC
Magnetic Properties Remanence Ratio Brbs
0.76
Magnetic Properties Saturation Flux Density
1.56 T
Magnetic Properties Saturation Magnetostriction
27 x10-6
Mechanical Properties Hardness Vickers
860 Kgf mm-2
Mechanical Properties Tensile Modulus
57.00 GPa
Mechanical Properties Tensile Strength
> 700.00 MPa
Physical Properties Density
7.180 g·cm-3
Specifications Coil Width
50 mm
Specifications Form
Foil
Specifications Grade
Metallic Glass
Specifications Thickness
0.025 mm
Thermal Properties Crystallization Temperature
550 ºC
Thermal Properties Maximum Use Temperature In Air
150 ºC
Tolerances Tolerance For 001 Millimeter Mm Thickness
0.25 %
Tolerances Tolerance For 005 Millimeter Mm Thickness
10 %
Tolerances Tolerance For 100 Millimeter Mm Coil Length
+2 % | -1 %
Tolerances Tolerance For 100 Millimeter Mm Disc Diameter
+2 % | -1 %
Tolerances Tolerance For 100 Millimeter Mm Length 1 Light Tight
+2 % | -1 %
Tolerances Tolerance For 100 Millimeter Mm Length 2 Light Tight
+2 % | -1 %
Type Type
GlassGoodfellow offers two distinct types of glass products: The first are generally silica-based, non-crystalline (amorphous) solids which exhibit a glass transition and are brittle and transparent. The properties of glass materials can be readily modified to alter their optical performance and other characteristics. This type is available through Goodfellow's Ceramic and Glass Division. Generally, these products are made to order for customers, so we do not list them in our Catalog. Please contact us with your requirements. The second type of glass product is commonly referred to as "metallic glasses" or "glassy metals". In contrast to crystalline metals and alloys with highly ordered atomic structures, these are non-crystalline (amorphous) metals or, more usually, alloys. Our website details those glassy metals which are available from stock; please contact us if you are unable to find the item you specifically require.
