Fiberglass Concrete Handhole Assembly - 21-inch Inside Depth
Fiberglass Concrete Handhole Assembly - 21-inch Inside Depth
SKU:HAN-5f9d33
Enhance infrastructure with newbasis PCX™ Fiberglass Concrete Handhole Assembly - Straight-sided design, ASTM Compliant, Skid-resistant cover.
Regular price
$549.99
Regular price
Sale price
$549.99
Unit price
per
Initiate Order
Fiberglass Concrete Handhole Assembly - 21-inch Inside Depth
$549.99
Quantity: 1
Claim Your Seller Account
Fiberglass Concrete Handhole Assembly - 21-inch Inside Depth
$549.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your infrastructure with this high-quality Fiberglass Concrete Handhole Assembly. Manufactured by newbasis PCX™, this assembly features a straight-sided design, stainless steel 3/8-inch Hex Bolts, and comprehensive ASTM compliance. With a high Compressive Strength of 87 MPa and top-notch Flexural Strength, this assembly is ideal for demanding environments. The assembly includes a skid-resistant cover, drop-in nameplate, and integral drain holes for added convenience. Customize with various options including Penta Bolts, Custom Nameplates, and more.
Product Specifications
Available Options
Penta Bolts, Telephone EMS, Power EMS, Racks, Knockouts, Floor, Custom Nameplate Installed, Custom Nameplate Shipped Separately, Standard Nameplate Installed, Standard Nameplate Shipped Separately
Dimensional Attributes Height
24 in
Dimensional Attributes Inside Depth
21 in
Dimensional Attributes Inside Length
28 1/16 in | 33 1/8 in
Dimensional Attributes Inside Width For 28 116 In Length
16 1/2 in
Dimensional Attributes Inside Width For 33 18 In Length
22 1/2 in
Dimensional Attributes Length
36 in
Dimensional Attributes Width
24 in
Features
USDA/RUS ApprovedDrop-In nameplateShipped assembledSkid resistant coverCast-in floating nut box - Integral drain holes
Load Ratings
Incidental Traffic - Parking Lot, Sidewalk Conforms to:WUC 3.6ASTM C 857ANSI/SCTE 77
Material Properties
Advanced composite: Very high strength to weight ratioNon-metallicNon-conductiveUV ResistantHigh impact resistantImpervious to chemicals and moistureMaterials tested in accordance with ASTM D-543 and ASTM D-570
Nameplates
One standard nameplate included with each assembly, installed at the factory or easily installed in the field. Custom nameplates are available. Contact customer service.Standard NameplatesElectricTelephoneFiber OpticWaterIrrigation Control ValveBroadbandTrafficCATVTraffic SignalCommunications
Specifications Assembly Weight
248 lb
Specifications Bolt Head Type
Hex
Specifications Bolt Material
Stainless Steel
Specifications Bolt Size
3/8 in
Specifications Box Weight
126 lb
Specifications Brand
newbasis, PCX™
Specifications Coefficient Of Friction Dry Per American Society
1.085
Specifications Compressive Strength Per American Society For Tes
87 MPa
Specifications Cover Weight
122 lb
Specifications Fiber Reinforced Polymers Frp Compressive Strengt
134 MPa
Specifications Fiber Reinforced Polymers Frp Flexural Strength P
116 MPa
Specifications Flexural Strength Per American Society For Testin
20 MPa
Specifications Industry Standardscertifications
WUC 3.6 -''20K''
Specifications Loaded Pallet Weight
1595 lb
Specifications Material
Fiberglass Concrete
Specifications Packaging
Steel Banding, Edge Protection
Specifications Pallet Quantity
6
Specifications Side
Straight
Specifications Type
Fiberglass Concrete Assemblies
