Flat Board Side x .125 Chassis Hole Circuit Board Support (53 Series)
Flat Board Side x .125 Chassis Hole Circuit Board Support (53 Series)
SKU:01C-10d4b8
Effortlessly install loaded PC boards with our durable Circuit Board Support from the 53 Series. Compliant with UL standards and RoHS regulations.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Flat Board Side x .125 Chassis Hole Circuit Board Support (53 Series)
$24.99
Quantity: 1
Claim Your Seller Account
Flat Board Side x .125 Chassis Hole Circuit Board Support (53 Series)
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Flat Board Side x .125 Chassis Hole Circuit Board Support from the 53 Series offers effortless installation on chassis without the need for tools or screws. Designed to accommodate loaded PC boards, this product is crafted from durable Nylon 66 UL94V-2 material (UL94V-0 available for enhanced fire safety). Compliant with UL File No E41938, ASTM D 4066, PA111, and RoHS standards, this support withstands temperatures from -40 to 185F (-40 to 85C), ensuring reliable performance in various environments.
Product Specifications
Specifications Dim L
.437 (11.1) inches (mm)
