Foot Operated Hydraulic Pump - FP-AC Series with Reservoirs
Foot Operated Hydraulic Pump - FP-AC Series with Reservoirs
SKU:HYD-c9b1e2
Enhance efficiency with the Foot Operated Hydraulic Pump - FP-AC Series. Features an oil reservoir, adjustable overload relief valve, and manual pressure release.
Regular price
$705.00
Regular price
Sale price
$705.00
Unit price
per
Initiate Order
Foot Operated Hydraulic Pump - FP-AC Series with Reservoirs
$705.00
Quantity: 1
Claim Your Seller Account
Foot Operated Hydraulic Pump - FP-AC Series with Reservoirs
$705.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Foot Operated Hydraulic Pump - FP-AC Series with Reservoirs is a reliable solution for single-speed hydraulic pumping needs. This base-mounted pump features an oil reservoir, adjustable overload relief valve, and manual pressure release valve for enhanced safety and control. With a maximum pressure rating of 250 psi and a durable all-steel construction, this pump is designed for efficiency and longevity. The pistons are ground and hard chrome plated for smooth operation, and the pump includes a standard 80 in³ reservoir volume. Ideal for industrial applications requiring precise hydraulic pressure control.
Product Specifications
Specifications Adjustable Overload Relief Valve
Yes
Specifications Body Material
Steel
Specifications Foot Lever Load Per 100 Psi
37.0 lb
Specifications List Price
705 USD
Specifications Manual Pressure Release Valve
Yes
Specifications Maximum Pressure Rating
250 psi
Specifications Net Weight Wo Oil
22-26 lb
Specifications Oil Reservoir
true
Specifications Operating Lever Size
24 in
Specifications Outlet Port Size Nptf
3/8
Specifications Piston
Hard Chrome Plated
Specifications Piston Diameter
2 in
Specifications Reservoir Volume
80 in³
Specifications Series
FP
Specifications Type
Base Mounted
Specifications Volume Per Stroke
4.71 in³
Technical Information 0
Limited WarrantyAll Star pumps are covered by a limited warranty on materials and workmanship for one year from the date of manufacture. Star will repair or replace at its option any pump in which Star finds manufacturing defects. In order to get warranty service a pump must be returned to the Star plant freight prepaid with a written explanation of the problem.Technical DataLight hydraulic oil is recommended for use with Star pumps. Oils with SUS viscosity of 75 to 150 at 100 degrees Fahrenheit will give satisfactory performance (ISO grade 15, 22, or 32). In an emergency situation when the above oils are not available, use 5 W or 10 W motor oil or automatic transmission fluid.All exposed surfaces of standard Star pumps are painted with one coat of industrial quality paint. Pumps painted with special colors with two coat finishes, or with prime coat only, and pumps with special plated or polished parts, are also available.
