Foot Operated Hydraulic Pumps - FCP-LR & FCP-PL Series
Foot Operated Hydraulic Pumps - FCP-LR & FCP-PL Series
SKU:HYD-09c6da
Efficient foot-operated hydraulic pumps for rapid low to high pressure transitions, ideal for industrial applications.
Regular price
$931.00
Regular price
Sale price
$931.00
Unit price
per
Initiate Order
Foot Operated Hydraulic Pumps - FCP-LR & FCP-PL Series
$931.00
Quantity: 1
Claim Your Seller Account
Foot Operated Hydraulic Pumps - FCP-LR & FCP-PL Series
$931.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Foot Operated Hydraulic Pumps - FCP-LR & FCP-PL Series without Reservoirs are expertly designed for equipment with built-in reservoirs, offering two-speed functionality for efficient operation. Featuring an adjustable overload relief valve and manual pressure release valve, these pumps deliver rapid movement at low pressure and automatically switch to high pressure when maximum force is required. With options for base or flange mounting, these steel-bodied pumps provide a maximum pressure rating of 5000 psi, making them ideal for industrial applications that demand precision and reliability.
Product Specifications
Specifications Adjustable Overload Relief Valve
Yes
Specifications Body Material
Steel
Specifications Foot Lever Load Per 1000 Psi
23.0 lb
Specifications Inlet Port Size Nptf
Unthreaded hole
Specifications List Price
931 USD
Specifications Manual Pressure Release Valve
Yes
Specifications Maximum Pressure Rating
5000 psi
Specifications Mounting
Flange Mounted
Specifications Net Weight
23 lb
Specifications Oil Reservoir
false
Specifications Operating Lever Size
24 in
Specifications Outlet Port Size Nptf
3/8
Specifications Piston
Hard Chrome Plated
Specifications Piston Diameter
2-1/2 in
Specifications Series
FCP-PL
Specifications Volume Per Stroke Large Piston To 300 Psi Approx
4.71 in³
Specifications Volume Per Stroke Small Piston Above 300 Psi Appr
0.29 in³
Technical Information 0
Limited WarrantyAll Star pumps are covered by a limited warranty on materials and workmanship for one year from the date of manufacture. Star will repair or replace at its option any pump in which Star finds manufacturing defects. In order to get warranty service a pump must be returned to the Star plant freight prepaid with a written explanation of the problem.Technical DataLight hydraulic oil is recommended for use with Star pumps. Oils with SUS viscosity of 75 to 150 at 100 degrees Fahrenheit will give satisfactory performance (ISO grade 15, 22, or 32). In an emergency situation when the above oils are not available, use 5 W or 10 W motor oil or automatic transmission fluid.All exposed surfaces of standard Star pumps are painted with one coat of industrial quality paint. Pumps painted with special colors with two coat finishes, or with prime coat only, and pumps with special plated or polished parts, are also available.
