Foot Operated Hydraulic Pumps - FSP-A & FSP-PL Series
Foot Operated Hydraulic Pumps - FSP-A & FSP-PL Series
SKU:HYD-8735b9
Reliable Foot Operated Hydraulic Pumps for emergency hydraulic power needs, offering 2500 psi maximum pressure rating and steel construction.
Regular price
$457.00
Regular price
Sale price
$457.00
Unit price
per
Initiate Order
Foot Operated Hydraulic Pumps - FSP-A & FSP-PL Series
$457.00
Quantity: 1
Claim Your Seller Account
Foot Operated Hydraulic Pumps - FSP-A & FSP-PL Series
$457.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Foot Operated Hydraulic Pumps - FSP-A & FSP-PL Series provide a cost-efficient solution for developing or increasing pressure in hydraulic systems. With a maximum pressure rating of 2500 psi, hard chrome plated piston, and steel body construction, these pumps are reliable for emergencies and stand-by operations. Available in hand or foot operated versions, with a flange mount option, they are suitable for various applications including medical, food handling, and corrosive environments. The pumps are ideal for equipment with existing reservoirs and control valves, offering a dependable hydraulic power source for presses, valves, doors, and safety locks.
Product Specifications
Specifications Adjustable Overload Relief Valve
No
Specifications Body Material
Steel
Specifications Foot Lever Load Per 100 Psi
5.2 lb
Specifications Inlet Port Size Nptf
3/8
Specifications List Price
457 USD
Specifications Manual Pressure Release Valve
No
Specifications Maximum Pressure Rating
2500 psi
Specifications Mounting
Flange Mounted
Specifications Net Weight
11 lb
Specifications Oil Reservoir
false
Specifications Operating Lever Size
24 in
Specifications Outlet Port Size Nptf
3/8
Specifications Piston
Hard Chrome Plated
Specifications Piston Diameter
3/4 in
Specifications Series
FSP-PL
Specifications Volume Per Stroke
0.66 in³
Technical Information 0
Limited WarrantyAll Star pumps are covered by a limited warranty on materials and workmanship for one year from the date of manufacture. Star will repair or replace at its option any pump in which Star finds manufacturing defects. In order to get warranty service a pump must be returned to the Star plant freight prepaid with a written explanation of the problem.Technical DataLight hydraulic oil is recommended for use with Star pumps. Oils with SUS viscosity of 75 to 150 at 100 degrees Fahrenheit will give satisfactory performance (ISO grade 15, 22, or 32). In an emergency situation when the above oils are not available, use 5 W or 10 W motor oil or automatic transmission fluid.All exposed surfaces of standard Star pumps are painted with one coat of industrial quality paint. Pumps painted with special colors with two coat finishes, or with prime coat only, and pumps with special plated or polished parts, are also available.
