Foot Operated Hydraulic Pumps - Steel & Stainless Steel Models
Foot Operated Hydraulic Pumps - Steel & Stainless Steel Models
SKU:HYD-9b448f
Get reliable hydraulic power with Foot Operated Hydraulic Pumps - Steel & Stainless Steel Models. Ideal for emergency and standby use. 1-year warranty included.
Regular price
$325.00
Regular price
Sale price
$325.00
Unit price
per
Initiate Order
Foot Operated Hydraulic Pumps - Steel & Stainless Steel Models
$325.00
Quantity: 1
Claim Your Seller Account
Foot Operated Hydraulic Pumps - Steel & Stainless Steel Models
$325.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Foot Operated Hydraulic Pumps - FSP-A & FSP-PL Series are essential components for developing or boosting hydraulic pressure in systems that already have reservoirs and control valves. These pumps, available in steel or stainless steel with hard chrome-plated pistons, offer a cost-effective solution for emergencies and standby situations. With maximum pressures up to 1250 psi, inlet and outlet port sizes of 3/8 NPTF, and a foot lever load of 9.2 lb per 100 PSI, these pumps deliver reliable hydraulic power for various applications. Suitable for medical, food handling, and corrosive environments, these pumps come with a 1-year limited warranty and are designed for durability and performance.
Product Specifications
Specifications Adjustable Overload Relief Valve
No
Specifications Body Material
Steel
Specifications Foot Lever Load Per 100 Psi
9.2 lb
Specifications Inlet Port Size Nptf
3/8
Specifications List Price
325 USD
Specifications Manual Pressure Release Valve
No
Specifications Maximum Pressure Rating
1250 psi
Specifications Mounting
Base Mounted
Specifications Net Weight
11 lb
Specifications Oil Reservoir
false
Specifications Operating Lever Size
24 in
Specifications Outlet Port Size Nptf
3/8
Specifications Piston
Hard Chrome Plated
Specifications Piston Diameter
1 in
Specifications Series
FSP
Specifications Volume Per Stroke
1.18 in³
Technical Information 0
Limited WarrantyAll Star pumps are covered by a limited warranty on materials and workmanship for one year from the date of manufacture. Star will repair or replace at its option any pump in which Star finds manufacturing defects. In order to get warranty service a pump must be returned to the Star plant freight prepaid with a written explanation of the problem.Technical DataLight hydraulic oil is recommended for use with Star pumps. Oils with SUS viscosity of 75 to 150 at 100 degrees Fahrenheit will give satisfactory performance (ISO grade 15, 22, or 32). In an emergency situation when the above oils are not available, use 5 W or 10 W motor oil or automatic transmission fluid.All exposed surfaces of standard Star pumps are painted with one coat of industrial quality paint. Pumps painted with special colors with two coat finishes, or with prime coat only, and pumps with special plated or polished parts, are also available.
